SDO HMI 2014-10-02 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 21.98 | 0.00 | 12.42 | -4.64 | 139.29 | -26.21 | 112.67 | 0.4793 | -732.8 | -621.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-02 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.64 | -4.19 | 140.80 | -24.70 | 113.06 | 0.4548 | -847.0 | -689.0 | |
| 0.00 | 2.99 | 0.00 | 1.67 | -4.36 | 140.43 | -25.07 | 113.07 | 0.4612 | -701.0 | -589.1 | |
| 0.00 | 1.32 | 0.00 | 0.74 | -4.57 | 139.85 | -25.65 | 113.00 | 0.4706 | -830.0 | -681.5 | |
| 0.00 | 0.79 | 0.00 | 0.44 | -4.28 | 139.60 | -25.90 | 112.21 | 0.4725 | -792.0 | -638.3 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -6.19 | 139.41 | -26.09 | 115.69 | 0.4872 | -725.0 | -581.8 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -6.40 | 139.40 | -26.10 | 116.08 | 0.4888 | -541.0 | -473.8 | |
| 0.00 | 0.70 | 0.00 | 0.40 | -4.14 | 139.34 | -26.16 | 111.73 | 0.4754 | -460.0 | -413.5 | |
| 0.00 | 2.73 | 0.00 | 1.55 | -5.86 | 139.22 | -26.28 | 114.92 | 0.4876 | -749.0 | -599.9 | |
| 0.00 | 2.99 | 0.00 | 1.70 | -5.49 | 139.11 | -26.39 | 114.14 | 0.4869 | -837.0 | -731.1 | |
| 0.00 | 3.52 | 0.00 | 1.98 | -3.33 | 139.03 | -26.47 | 109.90 | 0.4752 | -927.0 | -705.4 | |
| 0.00 | 1.76 | 0.00 | 0.99 | -4.03 | 139.00 | -26.50 | 111.26 | 0.4795 | -663.0 | -564.2 | |
| 0.00 | 1.76 | 0.00 | 1.01 | -3.54 | 136.88 | -28.62 | 108.79 | 0.5070 | -722.0 | -520.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
