SDO HMI 2014-10-02 14:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.72 | 164.65 | 162.26 | 739.22 | -10.92 | 245.60 | 81.75 | 258.09 | 0.9911 | -204.4 | 93.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-02 14:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.59 | 100.85 | 57.17 | 614.83 | -10.23 | 247.68 | 83.83 | 259.09 | 0.9968 | -420.2 | 91.8 | |
| 0.26 | -1.00 | 1.73 | -1.00 | -10.81 | 248.14 | 84.28 | 258.57 | 0.9975 | -964.7 | 999999 | |
| 0.26 | -1.00 | 1.35 | -1.00 | -10.60 | 246.90 | 83.05 | 258.61 | 0.9957 | 441.0 | 999999 | |
| 9.68 | -1.00 | 58.48 | -1.00 | -11.03 | 247.34 | 83.49 | 258.25 | 0.9965 | -125.9 | 999999 | |
| 0.00 | 9.94 | 0.00 | 34.79 | -10.22 | 244.40 | 80.55 | 258.65 | 0.9908 | 354.0 | 314.9 | |
| 5.37 | -1.00 | 25.83 | -1.00 | -12.68 | 246.10 | 82.25 | 256.43 | 0.9949 | 143.8 | 999999 | |
| 10.56 | 47.35 | 17.70 | 79.99 | -10.77 | 234.89 | 71.04 | 256.53 | 0.9567 | -321.1 | -8.1 | |
| 0.00 | 1.76 | 0.00 | 2.63 | -8.62 | 233.05 | 69.19 | 258.42 | 0.9449 | 534.0 | 364.5 | |
| 0.00 | 1.85 | 0.00 | 2.72 | -8.79 | 232.69 | 68.84 | 258.17 | 0.9431 | 338.0 | 300.0 | |
| 0.00 | 0.88 | 0.00 | 1.33 | -10.59 | 232.98 | 69.12 | 256.35 | 0.9466 | -465.0 | -466.4 | |
| 0.00 | 1.14 | 0.00 | 1.67 | -9.89 | 232.31 | 68.46 | 256.94 | 0.9421 | -319.0 | -222.2 | |
| 0.00 | 0.88 | 0.00 | 1.26 | -10.06 | 231.89 | 68.03 | 256.68 | 0.9399 | -403.0 | -362.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
