SDO HMI 2014-10-02 15:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 94.16 | 526.80 | 47.94 | 267.95 | -1.53 | 153.18 | -10.13 | 129.08 | 0.2269 | 623.9 | 309.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-02 15:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 54.12 | 321.96 | 27.43 | 163.14 | -1.66 | 154.38 | -8.93 | 132.69 | 0.2120 | 1386.5 | 452.3 | |
| 0.88 | -1.00 | 0.45 | -1.00 | -1.52 | 153.68 | -9.63 | 130.04 | 0.2193 | 815.1 | 999999 | |
| 0.00 | 1.50 | 0.00 | 0.76 | -3.08 | 153.30 | -10.00 | 133.93 | 0.2420 | 675.0 | 502.8 | |
| 0.79 | 2.20 | 0.40 | 1.12 | -2.32 | 153.24 | -10.06 | 131.44 | 0.2338 | 883.9 | 717.8 | |
| 0.62 | 13.11 | 0.31 | 6.67 | -2.05 | 153.25 | -10.06 | 130.56 | 0.2307 | 917.3 | 875.4 | |
| 3.61 | -5.00 | 1.84 | -5.00 | -1.81 | 153.19 | -10.12 | 129.59 | 0.2288 | 1082.1 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.67 | -2.81 | 152.97 | -10.34 | 132.18 | 0.2430 | 829.0 | 724.6 | |
| 0.00 | 1.14 | 0.00 | 0.58 | -0.00 | 152.65 | -10.66 | 121.59 | 0.2181 | 980.0 | 749.2 | |
| 0.88 | 79.19 | 0.45 | 40.39 | -1.39 | 152.58 | -10.72 | 126.54 | 0.2325 | 1137.8 | 339.7 | |
| 10.91 | -9.00 | 5.56 | -9.00 | -1.70 | 152.52 | -10.79 | 127.41 | 0.2366 | 1019.3 | 999999 | |
| 1.06 | -9.00 | 0.54 | -9.00 | -1.27 | 152.52 | -10.78 | 125.96 | 0.2321 | 931.4 | 999999 | |
| 0.00 | 1.94 | 0.00 | 0.98 | 0.21 | 152.52 | -10.78 | 120.48 | 0.2180 | 716.0 | 633.0 | |
| 0.00 | 1.94 | 0.00 | 0.98 | -0.07 | 152.46 | -10.84 | 121.40 | 0.2213 | 1087.0 | 967.8 | |
| 2.55 | 13.20 | 1.30 | 6.72 | -0.46 | 152.28 | -11.02 | 122.45 | 0.2276 | 1131.3 | 730.3 | |
| 0.00 | 2.46 | 0.00 | 1.25 | 0.14 | 152.25 | -11.05 | 120.09 | 0.2226 | 1105.0 | 962.6 | |
| 1.06 | 2.46 | 0.54 | 1.26 | -1.17 | 151.69 | -11.61 | 123.59 | 0.2426 | 887.4 | 757.4 | |
| 0.00 | 1.32 | 0.00 | 0.68 | -2.60 | 151.59 | -11.71 | 127.96 | 0.2584 | 858.0 | 717.5 | |
| 0.00 | 2.55 | 0.00 | 1.30 | -0.34 | 151.15 | -12.16 | 119.46 | 0.2429 | 855.0 | 765.1 | |
| 0.00 | 2.73 | 0.00 | 1.39 | -0.85 | 151.02 | -12.28 | 121.01 | 0.2493 | 805.0 | 616.1 | |
| 0.00 | 0.70 | 0.00 | 0.36 | -1.07 | 150.96 | -12.34 | 121.60 | 0.2521 | 602.0 | 499.9 | |
| 0.00 | 5.19 | 0.00 | 2.65 | -0.25 | 150.81 | -12.49 | 118.48 | 0.2472 | 17.0 | -86.2 | |
| 0.00 | 4.93 | 0.00 | 2.52 | 0.19 | 150.44 | -12.86 | 116.19 | 0.2492 | -321.0 | -546.9 | |
| 0.00 | 1.23 | 0.00 | 0.63 | -1.11 | 150.31 | -12.99 | 120.43 | 0.2618 | -1012.0 | -751.4 | |
| 0.00 | 1.94 | 0.00 | 0.99 | -0.27 | 150.32 | -12.99 | 117.58 | 0.2547 | -864.0 | -619.5 | |
| 0.00 | 1.41 | 0.00 | 0.73 | -3.00 | 150.26 | -13.04 | 126.13 | 0.2802 | -993.0 | -787.2 | |
| 0.00 | 1.58 | 0.00 | 0.81 | 0.45 | 150.19 | -13.11 | 114.80 | 0.2510 | -1039.0 | -882.2 | |
| 3.70 | 17.33 | 1.90 | 8.92 | -1.25 | 149.63 | -13.67 | 119.58 | 0.2729 | -1062.7 | -672.6 | |
| 3.61 | 23.58 | 1.85 | 12.11 | -0.62 | 149.64 | -13.67 | 117.52 | 0.2676 | -1043.9 | -949.6 | |
| 2.02 | -28.00 | 1.04 | -28.00 | -0.56 | 149.48 | -13.82 | 117.07 | 0.2694 | -890.4 | 999999 | |
| 0.00 | 1.50 | 0.00 | 0.77 | -1.50 | 149.48 | -13.83 | 120.07 | 0.2773 | -887.0 | -720.5 | |
| 2.46 | -28.00 | 1.27 | -28.00 | -0.38 | 149.45 | -13.85 | 116.42 | 0.2685 | -952.6 | 999999 | |
| 0.00 | 2.99 | 0.00 | 1.55 | -1.51 | 149.01 | -14.29 | 119.27 | 0.2841 | -830.0 | -664.1 | |
| 0.00 | 1.41 | 0.00 | 0.73 | -2.18 | 148.95 | -14.36 | 121.15 | 0.2908 | -1002.0 | -867.4 | |
| 5.19 | 8.18 | 2.69 | 4.25 | -2.59 | 148.57 | -14.73 | 121.64 | 0.2998 | -1020.6 | -701.4 | |
| 0.70 | 3.70 | 0.37 | 1.92 | -2.34 | 148.54 | -14.76 | 120.90 | 0.2981 | -1056.2 | -817.8 | |
| 0.00 | 2.11 | 0.00 | 1.12 | -5.60 | 145.81 | -17.50 | 124.65 | 0.3653 | 790.0 | 645.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
