SDO HMI 2014-10-02 17:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.66 | 69.34 | 8.71 | 38.96 | -10.56 | 140.07 | -22.13 | 127.70 | 0.4709 | 371.0 | 361.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-02 17:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.66 | -17.44 | 142.51 | -19.69 | 141.32 | 0.5165 | 749.0 | 634.8 | |
| 0.00 | 0.97 | 0.00 | 0.56 | -15.42 | 140.19 | -22.01 | 135.50 | 0.5174 | 624.0 | 538.7 | |
| 2.20 | 53.14 | 1.22 | 29.59 | -9.79 | 140.51 | -21.69 | 127.04 | 0.4582 | 1156.7 | 584.8 | |
| 5.98 | -3.00 | 3.32 | -3.00 | -9.20 | 140.52 | -21.68 | 125.99 | 0.4526 | 1075.4 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.45 | -12.09 | 140.29 | -21.91 | 130.63 | 0.4827 | 764.0 | 640.1 | |
| 3.08 | -3.00 | 1.72 | -3.00 | -10.01 | 140.43 | -21.77 | 127.32 | 0.4612 | 939.0 | 999999 | |
| 4.40 | -3.00 | 2.45 | -3.00 | -9.54 | 140.46 | -21.74 | 126.54 | 0.4565 | 1163.5 | 999999 | |
| 0.00 | 1.50 | 0.00 | 0.88 | -16.52 | 139.59 | -22.61 | 136.23 | 0.5350 | 691.0 | 506.0 | |
| 0.00 | 1.06 | 0.00 | 0.60 | -11.73 | 139.89 | -22.31 | 129.54 | 0.4838 | 944.0 | 764.0 | |
| 0.00 | 0.97 | 0.00 | 0.55 | -11.80 | 139.69 | -22.51 | 129.40 | 0.4870 | 678.0 | 466.0 | |
| 0.00 | 1.06 | 0.00 | 0.62 | -15.77 | 138.25 | -23.95 | 133.58 | 0.5413 | -758.0 | -638.4 | |
| 0.00 | 1.58 | 0.00 | 0.92 | -13.64 | 138.47 | -23.73 | 130.77 | 0.5184 | -711.0 | -567.9 | |
| 0.00 | 1.14 | 0.00 | 0.67 | -13.99 | 137.86 | -24.34 | 130.56 | 0.5286 | -834.0 | -731.6 | |
| 0.00 | 2.20 | 0.00 | 1.27 | -12.80 | 137.95 | -24.25 | 128.89 | 0.5165 | -889.0 | -768.6 | |
| 0.00 | 0.53 | 0.00 | 0.31 | -15.35 | 137.59 | -24.61 | 132.22 | 0.5444 | -652.0 | -531.7 | |
| 0.00 | 0.97 | 0.00 | 0.56 | -12.42 | 137.35 | -24.85 | 127.61 | 0.5201 | -596.0 | -503.5 | |
| 0.00 | 1.41 | 0.00 | 0.81 | -11.62 | 136.99 | -25.21 | 125.95 | 0.5174 | -307.0 | -366.8 | |
| 0.00 | 0.88 | 0.00 | 0.51 | -12.45 | 136.80 | -25.40 | 127.05 | 0.5268 | -725.0 | -627.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
