SDO HMI 2014-10-03 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.82 | 117.97 | 24.65 | 75.06 | -13.28 | 119.70 | -33.70 | 120.77 | 0.6304 | 425.1 | 145.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-03 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.83 | 84.24 | 6.82 | 53.02 | -13.26 | 120.54 | -32.86 | 121.37 | 0.6207 | 885.4 | 341.9 | |
| 17.96 | -1.00 | 11.32 | -1.00 | -12.99 | 120.40 | -33.00 | 120.87 | 0.6205 | 993.7 | 999999 | |
| 0.00 | 3.43 | 0.00 | 2.18 | -13.70 | 120.25 | -33.15 | 121.75 | 0.6270 | -286.0 | -86.1 | |
| 2.90 | -1.00 | 1.83 | -1.00 | -12.71 | 120.33 | -33.07 | 120.42 | 0.6195 | 972.3 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.50 | -13.68 | 119.96 | -33.44 | 121.51 | 0.6303 | -71.0 | 31.8 | |
| 1.32 | 3.70 | 0.84 | 2.35 | -13.08 | 119.87 | -33.53 | 120.60 | 0.6274 | 609.3 | 404.3 | |
| 0.00 | 1.32 | 0.00 | 0.85 | -13.55 | 119.05 | -34.35 | 120.65 | 0.6399 | 81.0 | 74.1 | |
| 0.00 | 1.94 | 0.00 | 1.24 | -11.74 | 118.66 | -34.74 | 117.84 | 0.6333 | 709.0 | 596.7 | |
| 0.00 | 0.97 | 0.00 | 0.63 | -13.21 | 118.39 | -35.01 | 119.72 | 0.6454 | -267.0 | -379.5 | |
| 1.32 | 8.63 | 0.87 | 5.68 | -14.90 | 117.97 | -35.43 | 121.71 | 0.6607 | -646.9 | -571.5 | |
| 3.08 | -10.00 | 2.03 | -10.00 | -14.66 | 117.83 | -35.57 | 121.28 | 0.6608 | -778.7 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.63 | -13.31 | 117.96 | -35.44 | 119.54 | 0.6509 | 367.0 | 250.7 | |
| 0.00 | 1.06 | 0.00 | 0.69 | -14.09 | 117.74 | -35.66 | 120.45 | 0.6582 | 548.0 | 431.0 | |
| 0.00 | 0.62 | 0.00 | 0.41 | -15.82 | 116.90 | -36.50 | 122.15 | 0.6782 | -571.0 | -441.6 | |
| 0.53 | 2.02 | 0.35 | 1.34 | -13.67 | 116.90 | -36.50 | 119.31 | 0.6652 | -729.3 | -647.5 | |
| 0.00 | 2.38 | 0.00 | 1.59 | -14.72 | 116.47 | -36.93 | 120.43 | 0.6763 | -640.0 | -597.4 | |
| 0.88 | 4.67 | 0.59 | 3.12 | -13.36 | 115.91 | -37.49 | 118.26 | 0.6746 | -779.6 | -624.2 | |
| 0.00 | 1.23 | 0.00 | 0.83 | -13.12 | 115.64 | -37.76 | 117.77 | 0.6763 | -705.0 | -568.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
