SDO HMI 2014-10-04 06:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.41 | 29.21 | 0.73 | 15.30 | -11.91 | 139.34 | -2.51 | 172.36 | 0.3219 | 41.2 | 389.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-04 06:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.43 | -16.09 | 140.41 | -1.44 | 176.42 | 0.3875 | 831.0 | 640.2 | |
| 1.41 | 13.81 | 0.73 | 7.14 | -9.94 | 140.39 | -1.46 | 174.97 | 0.2864 | 1194.8 | 880.9 | |
| 0.00 | 1.41 | 0.00 | 0.76 | -15.99 | 140.22 | -1.62 | 175.94 | 0.3862 | 857.0 | 640.9 | |
| 0.00 | 2.29 | 0.00 | 1.23 | -16.15 | 140.16 | -1.69 | 175.81 | 0.3888 | 828.0 | 751.1 | |
| 0.00 | 1.32 | 0.00 | 0.68 | -9.53 | 140.18 | -1.67 | 174.10 | 0.2799 | 1141.0 | 875.5 | |
| 0.00 | 0.88 | 0.00 | 0.47 | -15.25 | 139.05 | -2.80 | 172.77 | 0.3761 | -811.0 | -743.0 | |
| 0.00 | 0.97 | 0.00 | 0.52 | -15.02 | 138.83 | -3.01 | 172.14 | 0.3729 | -840.0 | -752.0 | |
| 0.00 | 1.23 | 0.00 | 0.63 | -8.35 | 138.67 | -3.18 | 167.97 | 0.2642 | 747.0 | 703.7 | |
| 0.00 | 2.64 | 0.00 | 1.41 | -15.51 | 138.36 | -3.49 | 171.13 | 0.3818 | -814.0 | -541.9 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -12.57 | 137.11 | -4.73 | 166.18 | 0.3387 | -788.0 | -630.6 | |
| 0.00 | 2.20 | 0.00 | 1.15 | -11.61 | 135.22 | -6.62 | 160.04 | 0.3325 | -753.0 | -581.9 | |
| 0.00 | 0.79 | 0.00 | 0.42 | -10.90 | 133.88 | -7.96 | 155.55 | 0.3300 | -787.0 | -563.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
