SDO HMI 2014-10-04 07:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.29 | 22.96 | 8.25 | 17.77 | 12.95 | 90.86 | -50.44 | 78.69 | 0.7671 | 331.1 | 11.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-04 07:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.32 | 0.00 | 0.83 | 9.93 | 102.94 | -38.36 | 82.26 | 0.6192 | -585.0 | -528.7 | |
| 0.00 | 0.62 | 0.00 | 0.43 | 10.68 | 96.69 | -44.61 | 81.41 | 0.7002 | -486.0 | -456.3 | |
| 0.00 | 1.58 | 0.00 | 1.09 | 8.04 | 96.95 | -44.35 | 85.20 | 0.6970 | -529.0 | -502.3 | |
| 0.00 | 1.41 | 0.00 | 1.00 | 10.99 | 95.24 | -46.06 | 81.03 | 0.7180 | -149.0 | -178.8 | |
| 0.00 | 2.11 | 0.00 | 1.53 | 10.76 | 93.85 | -47.45 | 81.40 | 0.7343 | -405.0 | -252.5 | |
| 0.00 | 1.14 | 0.00 | 0.92 | 13.73 | 89.12 | -52.18 | 77.67 | 0.7878 | 522.0 | 426.0 | |
| 10.29 | 13.11 | 8.25 | 10.50 | 13.36 | 89.08 | -52.22 | 78.14 | 0.7880 | 759.4 | 440.1 | |
| 0.00 | 1.67 | 0.00 | 1.47 | 19.19 | 85.50 | -55.79 | 71.20 | 0.8273 | 417.0 | 323.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
