SDO HMI 2014-10-04 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 54.36 | 201.49 | 30.92 | 115.28 | -12.71 | 162.11 | 23.00 | 229.65 | 0.5014 | 40.4 | 202.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-04 11:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.41 | 0.00 | 0.90 | -15.06 | 172.21 | 33.10 | 236.40 | 0.6354 | 633.0 | 564.8 | |
| 0.00 | 0.70 | 0.00 | 0.46 | -21.22 | 170.34 | 31.23 | 227.02 | 0.6630 | 363.0 | 406.5 | |
| 0.00 | 0.88 | 0.00 | 0.52 | -9.72 | 168.27 | 29.16 | 241.03 | 0.5511 | 580.0 | 473.8 | |
| 0.00 | 0.88 | 0.00 | 0.52 | -10.43 | 167.54 | 28.43 | 239.26 | 0.5468 | 716.0 | 596.6 | |
| 0.00 | 0.79 | 0.00 | 0.47 | -11.21 | 167.44 | 28.33 | 237.94 | 0.5514 | 677.0 | 574.7 | |
| 0.00 | 1.76 | 0.00 | 1.05 | -14.10 | 166.43 | 27.32 | 232.60 | 0.5624 | 563.0 | 484.2 | |
| 0.00 | 1.58 | 0.00 | 0.94 | -13.68 | 166.27 | 27.16 | 233.06 | 0.5570 | 741.0 | 627.7 | |
| 0.00 | 2.20 | 0.00 | 1.31 | -13.99 | 166.24 | 27.13 | 232.57 | 0.5593 | 586.0 | 565.0 | |
| 0.00 | 1.14 | 0.00 | 0.71 | -19.39 | 166.72 | 27.61 | 225.80 | 0.6120 | 674.0 | 469.0 | |
| 0.00 | 1.85 | 0.00 | 1.09 | -13.20 | 165.72 | 26.61 | 233.22 | 0.5467 | 739.0 | 667.1 | |
| 0.00 | 0.97 | 0.00 | 0.57 | -14.06 | 165.66 | 26.55 | 231.88 | 0.5532 | 717.0 | 508.9 | |
| 0.00 | 1.14 | 0.00 | 0.66 | -9.83 | 165.15 | 26.04 | 237.97 | 0.5122 | 766.0 | 633.2 | |
| 0.79 | 87.77 | 0.46 | 50.66 | -11.93 | 164.56 | 25.45 | 233.94 | 0.5222 | -135.4 | 537.7 | |
| 15.48 | -13.00 | 8.95 | -13.00 | -12.25 | 163.98 | 24.87 | 232.81 | 0.5180 | 947.6 | 999999 | |
| 8.53 | -13.00 | 4.91 | -13.00 | -12.17 | 163.60 | 24.49 | 232.51 | 0.5128 | 1127.5 | 999999 | |
| 0.44 | -13.00 | 0.25 | -13.00 | -11.69 | 163.56 | 24.45 | 233.22 | 0.5080 | 1068.2 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -10.92 | 163.22 | 24.11 | 234.09 | 0.4972 | -287.0 | -256.6 | |
| 0.00 | 1.41 | 0.00 | 0.80 | -10.44 | 163.01 | 23.90 | 234.66 | 0.4904 | -773.0 | -651.9 | |
| 6.95 | 12.93 | 4.00 | 7.45 | -12.78 | 163.16 | 24.05 | 231.05 | 0.5131 | 892.6 | 683.1 | |
| 0.00 | 1.67 | 0.00 | 0.96 | -11.86 | 163.00 | 23.89 | 232.32 | 0.5028 | 914.0 | 810.7 | |
| 1.06 | 2.99 | 0.61 | 1.72 | -12.39 | 162.88 | 23.77 | 231.34 | 0.5062 | 934.1 | 848.2 | |
| 0.00 | 2.29 | 0.00 | 1.30 | -10.92 | 162.52 | 23.41 | 233.29 | 0.4886 | -751.0 | -538.3 | |
| 0.00 | 2.29 | 0.00 | 1.31 | -12.40 | 162.45 | 23.34 | 230.81 | 0.5012 | 1009.0 | 770.6 | |
| 0.00 | 2.46 | 0.00 | 1.39 | -11.33 | 161.85 | 22.74 | 231.81 | 0.4843 | 608.0 | 499.8 | |
| 0.00 | 0.62 | 0.00 | 0.35 | -14.22 | 161.86 | 22.75 | 227.30 | 0.5121 | 973.0 | 808.4 | |
| 0.00 | 5.54 | 0.00 | 3.18 | -14.07 | 161.54 | 22.43 | 227.12 | 0.5072 | 979.0 | 697.5 | |
| 0.00 | 1.23 | 0.00 | 0.69 | -10.67 | 161.14 | 22.03 | 232.03 | 0.4695 | -693.0 | -583.4 | |
| 0.00 | 0.88 | 0.00 | 0.50 | -13.93 | 160.63 | 21.52 | 226.13 | 0.4957 | -702.0 | -441.2 | |
| 0.00 | 1.32 | 0.00 | 0.75 | -13.95 | 160.30 | 21.19 | 225.67 | 0.4923 | 839.0 | 564.1 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -14.22 | 159.96 | 20.85 | 224.80 | 0.4915 | -659.0 | -503.6 | |
| 0.00 | 1.58 | 0.00 | 0.90 | -14.46 | 159.48 | 20.37 | 223.80 | 0.4890 | -667.0 | -591.4 | |
| 0.00 | 1.85 | 0.00 | 1.05 | -14.65 | 159.50 | 20.39 | 223.54 | 0.4913 | -669.0 | -501.9 | |
| 0.00 | 0.97 | 0.00 | 0.54 | -13.39 | 159.22 | 20.11 | 225.02 | 0.4748 | -690.0 | -562.5 | |
| 0.00 | 2.55 | 0.00 | 1.44 | -14.16 | 159.19 | 20.08 | 223.83 | 0.4827 | -701.0 | -554.4 | |
| 0.00 | 2.64 | 0.00 | 1.47 | -12.59 | 158.96 | 19.85 | 225.90 | 0.4634 | -636.0 | -631.8 | |
| 0.00 | 0.53 | 0.00 | 0.30 | -13.32 | 158.99 | 19.88 | 224.80 | 0.4715 | -622.0 | -470.5 | |
| 0.00 | 2.02 | 0.00 | 1.14 | -14.02 | 158.95 | 19.84 | 223.69 | 0.4787 | -835.0 | -667.6 | |
| 1.85 | 3.69 | 1.02 | 2.04 | -10.71 | 158.59 | 19.48 | 228.47 | 0.4396 | -850.2 | -727.9 | |
| 0.00 | 0.97 | 0.00 | 0.53 | -10.77 | 158.44 | 19.33 | 228.14 | 0.4383 | -799.0 | -680.0 | |
| 1.76 | 5.98 | 0.99 | 3.35 | -13.66 | 158.62 | 19.51 | 223.76 | 0.4712 | -820.5 | -725.5 | |
| 0.00 | 0.97 | 0.00 | 0.55 | -14.49 | 158.56 | 19.45 | 222.45 | 0.4797 | -795.0 | -548.5 | |
| 0.00 | 1.50 | 0.00 | 0.83 | -12.43 | 158.23 | 19.12 | 225.07 | 0.4536 | -769.0 | -589.4 | |
| 0.00 | 1.06 | 0.00 | 0.59 | -14.13 | 158.37 | 19.26 | 222.68 | 0.4737 | -798.0 | -643.5 | |
| 0.00 | 1.58 | 0.00 | 0.88 | -13.57 | 158.16 | 19.05 | 223.19 | 0.4654 | -683.0 | -555.1 | |
| 0.00 | 2.02 | 0.00 | 1.12 | -11.73 | 157.98 | 18.87 | 225.85 | 0.4433 | -949.0 | -730.1 | |
| 0.00 | 1.32 | 0.00 | 0.73 | -12.74 | 158.02 | 18.91 | 224.28 | 0.4548 | -928.0 | -894.3 | |
| 0.00 | 1.32 | 0.00 | 0.73 | -12.39 | 158.00 | 18.89 | 224.79 | 0.4507 | -801.0 | -636.7 | |
| 0.00 | 1.23 | 0.00 | 0.68 | -11.88 | 157.80 | 18.69 | 225.32 | 0.4429 | -949.0 | -780.8 | |
| 17.50 | 22.16 | 9.73 | 12.33 | -13.17 | 157.73 | 18.62 | 223.16 | 0.4565 | -1026.3 | -742.5 | |
| 0.00 | 1.58 | 0.00 | 0.87 | -14.50 | 154.57 | 15.46 | 216.01 | 0.4408 | -786.0 | -688.6 | |
| 0.00 | 0.88 | 0.00 | 0.48 | -14.45 | 154.15 | 15.04 | 215.32 | 0.4363 | -729.0 | -605.2 | |
| 0.00 | 0.79 | 0.00 | 0.43 | -13.51 | 153.61 | 14.50 | 215.65 | 0.4194 | 780.0 | 586.3 | |
| 0.00 | 1.32 | 0.00 | 0.74 | -18.39 | 150.65 | 11.54 | 204.36 | 0.4623 | -705.0 | -480.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
