SDO HMI 2014-10-04 20:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 16.95 | 0.00 | 11.04 | -20.21 | 103.98 | -30.17 | 133.07 | 0.6453 | 77.6 | 34.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-04 20:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.35 | 0.00 | 0.21 | -22.70 | 113.27 | -20.88 | 145.67 | 0.5854 | 557.0 | 533.5 | |
| 0.00 | 1.05 | 0.00 | 0.65 | -22.53 | 112.39 | -21.76 | 144.41 | 0.5906 | 759.0 | 615.8 | |
| 0.00 | 0.88 | 0.00 | 0.54 | -22.36 | 110.80 | -23.35 | 142.33 | 0.6020 | 617.0 | 493.8 | |
| 0.00 | 1.32 | 0.00 | 0.82 | -22.45 | 110.40 | -23.76 | 141.96 | 0.6064 | 688.0 | 598.1 | |
| 0.00 | 0.26 | 0.00 | 0.15 | -15.45 | 111.07 | -23.08 | 134.07 | 0.5280 | 565.0 | 655.0 | |
| 0.00 | 1.14 | 0.00 | 0.66 | -15.20 | 110.90 | -23.25 | 133.51 | 0.5273 | 711.0 | 578.6 | |
| 0.00 | 1.85 | 0.00 | 1.17 | -23.77 | 109.50 | -24.66 | 142.37 | 0.6276 | 507.0 | 384.0 | |
| 0.00 | 0.97 | 0.00 | 0.58 | -16.76 | 108.19 | -25.97 | 132.53 | 0.5711 | 604.0 | 486.1 | |
| 0.00 | 1.49 | 0.00 | 0.91 | -15.08 | 105.80 | -28.35 | 127.77 | 0.5822 | 738.0 | 649.9 | |
| 0.00 | 1.58 | 0.00 | 1.28 | -30.41 | 95.58 | -38.58 | 137.15 | 0.7930 | -406.0 | -332.1 | |
| 0.00 | 1.41 | 0.00 | 0.94 | -17.31 | 99.07 | -35.08 | 125.03 | 0.6724 | -756.0 | -610.7 | |
| 0.00 | 1.23 | 0.00 | 0.82 | -17.51 | 98.95 | -35.20 | 125.20 | 0.6751 | -771.0 | -567.2 | |
| 0.00 | 1.85 | 0.00 | 1.24 | -17.49 | 98.72 | -35.43 | 125.01 | 0.6774 | -739.0 | -571.3 | |
| 0.00 | 1.05 | 0.00 | 0.71 | -17.31 | 98.06 | -36.09 | 124.30 | 0.6830 | -587.0 | -451.0 | |
| 0.00 | 0.26 | 0.00 | 0.18 | -16.95 | 98.15 | -36.01 | 123.89 | 0.6798 | -709.0 | -696.0 | |
| 0.00 | 0.26 | 0.00 | 0.18 | -16.93 | 96.98 | -37.18 | 123.06 | 0.6921 | -537.0 | -430.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
