SDO HMI 2014-10-05 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 14.06 | 0.00 | 7.56 | -13.25 | 137.75 | 10.74 | 208.36 | 0.3852 | -524.0 | -175.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-05 09:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.96 | 0.00 | 2.10 | -10.20 | 140.32 | 13.31 | 218.56 | 0.3652 | 956.0 | 851.1 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -15.61 | 139.15 | 12.14 | 208.44 | 0.4269 | -870.0 | -598.2 | |
| 0.00 | 0.79 | 0.00 | 0.43 | -14.53 | 138.80 | 11.79 | 209.02 | 0.4094 | -731.0 | -577.2 | |
| 0.00 | 2.73 | 0.00 | 1.53 | -18.68 | 138.99 | 11.98 | 204.93 | 0.4685 | -585.0 | -470.1 | |
| 0.00 | 1.67 | 0.00 | 0.88 | -11.73 | 135.96 | 8.95 | 206.06 | 0.3482 | -535.0 | -506.9 | |
| 0.00 | 1.14 | 0.00 | 0.61 | -14.18 | 135.92 | 8.91 | 203.12 | 0.3841 | -809.0 | -654.5 | |
| 0.00 | 1.14 | 0.00 | 0.60 | -10.39 | 135.02 | 8.01 | 205.35 | 0.3217 | -833.0 | -673.3 | |
| 0.00 | 1.49 | 0.00 | 0.78 | -11.36 | 132.22 | 5.21 | 196.21 | 0.3202 | -785.0 | -672.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
