SDO HMI 2014-10-05 12:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.63 | 319.96 | 36.57 | 184.51 | -1.37 | 155.12 | 29.75 | 256.20 | 0.5128 | 1082.0 | 365.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-05 12:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.25 | 287.28 | 23.26 | 165.99 | -1.42 | 155.38 | 30.02 | 256.24 | 0.5169 | 1242.8 | 352.7 | |
| 1.41 | -1.00 | 0.81 | -1.00 | -1.42 | 154.80 | 29.43 | 255.94 | 0.5084 | 1203.1 | 999999 | |
| 4.13 | -1.00 | 2.37 | -1.00 | -1.50 | 154.62 | 29.26 | 255.69 | 0.5062 | 1230.9 | 999999 | |
| 10.11 | 14.85 | 5.76 | 8.47 | -1.80 | 153.94 | 28.58 | 254.75 | 0.4975 | 927.9 | 632.1 | |
| 0.00 | 2.11 | 0.00 | 1.20 | 0.17 | 153.93 | 28.56 | 258.61 | 0.4897 | 649.0 | 565.5 | |
| 7.73 | 11.95 | 4.37 | 6.75 | -0.23 | 153.45 | 28.08 | 257.59 | 0.4840 | 982.5 | 773.2 | |
| 0.00 | 1.49 | 0.00 | 0.83 | 0.65 | 152.34 | 26.97 | 258.84 | 0.4642 | 736.0 | 606.0 | |
| 0.00 | 1.14 | 0.00 | 0.64 | 0.16 | 151.93 | 26.56 | 257.60 | 0.4598 | 679.0 | 603.3 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -0.27 | 150.76 | 25.40 | 256.03 | 0.4438 | -605.0 | -503.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
