SDO HMI 2014-10-05 13:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.83 | 21.53 | 3.80 | 17.85 | -18.53 | 77.24 | -47.58 | 119.06 | 0.8008 | 311.2 | 182.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-05 13:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.49 | 0.00 | 1.10 | -18.67 | 83.85 | -40.97 | 122.70 | 0.7405 | 460.0 | 397.4 | |
| 4.83 | 9.93 | 3.80 | 7.83 | -18.26 | 79.59 | -45.23 | 119.85 | 0.7795 | 713.2 | 502.7 | |
| 0.00 | 2.11 | 0.00 | 1.64 | -16.00 | 79.36 | -45.46 | 117.07 | 0.7716 | 588.0 | 408.2 | |
| 0.00 | 1.67 | 0.00 | 1.38 | -16.88 | 76.65 | -48.17 | 116.83 | 0.8012 | 459.0 | 398.2 | |
| 0.00 | 1.58 | 0.00 | 1.33 | -14.72 | 74.98 | -49.84 | 113.60 | 0.8088 | 460.0 | 357.1 | |
| 0.00 | 2.64 | 0.00 | 2.59 | -22.71 | 71.41 | -53.41 | 121.04 | 0.8664 | -372.0 | -287.5 | |
| 0.00 | 1.23 | 0.00 | 1.16 | -20.18 | 71.94 | -52.88 | 118.53 | 0.8539 | -473.0 | -436.9 | |
| 0.00 | 0.88 | 0.00 | 0.82 | -19.39 | 72.32 | -52.50 | 117.81 | 0.8482 | -471.0 | -398.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
