SDO HMI 2014-10-05 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.39 | 14.83 | 3.35 | 11.91 | -19.24 | 77.57 | -45.60 | 120.81 | 0.7860 | 336.8 | 254.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-05 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.59 | -20.81 | 82.25 | -40.91 | 125.26 | 0.7521 | 607.0 | 485.1 | |
| 4.39 | 8.34 | 3.35 | 6.38 | -18.21 | 79.61 | -43.56 | 120.68 | 0.7634 | 770.7 | 557.8 | |
| 0.00 | 0.79 | 0.00 | 0.59 | -15.82 | 79.49 | -43.68 | 117.74 | 0.7531 | 396.0 | 391.0 | |
| 0.00 | 1.05 | 0.00 | 1.02 | -26.55 | 72.40 | -50.76 | 126.25 | 0.8612 | -91.0 | -107.0 | |
| 0.00 | 1.58 | 0.00 | 1.26 | -16.83 | 76.65 | -46.51 | 117.54 | 0.7855 | 554.0 | 432.4 | |
| 0.00 | 0.53 | 0.00 | 0.44 | -19.05 | 75.83 | -47.34 | 119.72 | 0.8026 | 372.0 | 369.7 | |
| 0.00 | 0.70 | 0.00 | 0.67 | -22.81 | 71.12 | -52.05 | 121.72 | 0.8565 | -465.0 | -378.9 | |
| 0.00 | 1.05 | 0.00 | 0.96 | -20.19 | 71.92 | -51.25 | 119.22 | 0.8408 | -469.0 | -386.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
