SDO HMI 2014-10-05 18:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.51 | 0.00 | 6.30 | -13.15 | 137.85 | 15.79 | 218.40 | 0.4270 | -492.0 | -434.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-05 18:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.65 | -15.22 | 142.60 | 20.54 | 223.00 | 0.4983 | 707.0 | 455.3 | |
| 0.00 | 1.58 | 0.00 | 0.87 | -11.49 | 140.81 | 18.75 | 226.14 | 0.4387 | 133.0 | 142.3 | |
| 0.00 | 2.11 | 0.00 | 1.18 | -15.64 | 139.38 | 17.32 | 217.64 | 0.4714 | -810.0 | -695.9 | |
| 0.00 | 1.23 | 0.00 | 0.66 | -12.13 | 136.60 | 14.54 | 217.86 | 0.4015 | -933.0 | -743.5 | |
| 0.00 | 0.97 | 0.00 | 0.53 | -15.89 | 136.33 | 14.26 | 212.12 | 0.4475 | -755.0 | -580.1 | |
| 0.00 | 1.14 | 0.00 | 0.62 | -12.51 | 135.73 | 13.67 | 215.58 | 0.3982 | -831.0 | -672.5 | |
| 0.00 | 2.11 | 0.00 | 1.13 | -11.59 | 135.50 | 13.43 | 216.53 | 0.3840 | -869.0 | -732.1 | |
| 0.00 | 1.23 | 0.00 | 0.66 | -10.98 | 135.00 | 12.94 | 216.47 | 0.3713 | -578.0 | -442.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
