SDO HMI 2014-10-06 19:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.11 | 16.41 | 1.73 | 13.24 | -12.93 | 59.63 | -48.68 | 111.93 | 0.7910 | 119.0 | 295.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-06 19:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.88 | 5.53 | 0.69 | 4.33 | -12.94 | 60.99 | -47.33 | 112.48 | 0.7777 | 455.6 | 610.7 | |
| 0.00 | 3.16 | 0.00 | 2.49 | -12.74 | 60.68 | -47.64 | 112.11 | 0.7802 | 710.0 | 628.3 | |
| 0.00 | 1.58 | 0.00 | 1.26 | -13.05 | 60.37 | -47.95 | 112.36 | 0.7845 | 448.0 | 415.2 | |
| 0.00 | 0.79 | 0.00 | 0.63 | -12.55 | 60.31 | -48.01 | 111.73 | 0.7832 | 399.0 | 381.7 | |
| 0.00 | 1.49 | 0.00 | 1.25 | -13.40 | 58.14 | -50.17 | 111.89 | 0.8073 | -735.0 | -573.3 | |
| 0.00 | 0.88 | 0.00 | 0.75 | -14.16 | 57.48 | -50.84 | 112.52 | 0.8161 | 348.0 | 277.1 | |
| 1.23 | 2.98 | 1.04 | 2.53 | -12.52 | 57.13 | -51.19 | 110.47 | 0.8142 | -657.0 | -429.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
