SDO HMI 2014-10-07 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.11 | 150.04 | 20.02 | 85.77 | -14.10 | 121.81 | 21.74 | 226.18 | 0.4990 | 232.7 | 169.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-07 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.44 | -9.26 | 123.08 | 23.01 | 235.92 | 0.4676 | 688.0 | 495.2 | |
| 22.65 | 102.20 | 13.06 | 58.95 | -13.93 | 123.32 | 23.24 | 228.54 | 0.5131 | 1131.7 | 356.8 | |
| 0.00 | 0.88 | 0.00 | 0.50 | -12.90 | 122.95 | 22.87 | 229.67 | 0.4990 | 823.0 | 610.2 | |
| 0.00 | 1.14 | 0.00 | 0.66 | -15.23 | 122.96 | 22.88 | 226.20 | 0.5219 | 611.0 | 404.0 | |
| 1.84 | 3.42 | 1.07 | 1.98 | -14.87 | 122.82 | 22.74 | 226.54 | 0.5168 | 901.4 | 744.2 | |
| 0.00 | 1.14 | 0.00 | 0.66 | -14.38 | 122.53 | 22.45 | 226.90 | 0.5087 | 927.0 | 687.1 | |
| 1.23 | 2.55 | 0.70 | 1.46 | -14.45 | 122.07 | 21.99 | 226.20 | 0.5045 | 903.7 | 727.8 | |
| 0.00 | 1.32 | 0.00 | 0.75 | -14.01 | 120.73 | 20.65 | 225.07 | 0.4854 | 791.0 | 503.5 | |
| 0.00 | 1.67 | 0.00 | 0.94 | -13.07 | 120.31 | 20.24 | 225.93 | 0.4710 | 885.0 | 606.7 | |
| 0.00 | 1.05 | 0.00 | 0.59 | -14.69 | 118.56 | 18.48 | 220.90 | 0.4702 | -545.0 | -501.3 | |
| 0.00 | 1.67 | 0.00 | 0.94 | -14.94 | 118.45 | 18.37 | 220.38 | 0.4720 | -827.0 | -625.9 | |
| 0.00 | 1.84 | 0.00 | 1.04 | -15.20 | 118.40 | 18.33 | 219.95 | 0.4746 | -776.0 | -716.4 | |
| 0.00 | 0.61 | 0.00 | 0.35 | -15.49 | 118.40 | 18.32 | 219.54 | 0.4778 | -454.0 | -346.9 | |
| 0.00 | 1.14 | 0.00 | 0.64 | -15.25 | 118.21 | 18.14 | 219.58 | 0.4733 | -812.0 | -734.3 | |
| 0.00 | 1.84 | 0.00 | 1.02 | -13.97 | 117.36 | 17.28 | 220.06 | 0.4499 | 648.0 | 557.9 | |
| 1.58 | 6.85 | 0.89 | 3.85 | -16.06 | 117.40 | 17.33 | 217.21 | 0.4752 | -872.5 | -844.1 | |
| 1.05 | 12.38 | 0.58 | 6.82 | -13.29 | 116.86 | 16.78 | 220.25 | 0.4367 | -967.1 | -755.8 | |
| 2.55 | -17.00 | 1.40 | -17.00 | -13.51 | 116.84 | 16.77 | 219.89 | 0.4392 | -989.4 | 999999 | |
| 4.21 | -17.00 | 2.32 | -17.00 | -13.67 | 116.79 | 16.71 | 219.57 | 0.4405 | -885.4 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.59 | -15.46 | 116.86 | 16.79 | 217.14 | 0.4629 | -787.0 | -618.7 | |
| 0.00 | 1.32 | 0.00 | 0.72 | -13.31 | 116.67 | 16.59 | 219.89 | 0.4351 | -931.0 | -755.0 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -14.84 | 116.55 | 16.48 | 217.48 | 0.4524 | -793.0 | -516.1 | |
| 0.00 | 1.67 | 0.00 | 0.93 | -15.06 | 116.44 | 16.37 | 216.99 | 0.4541 | -710.0 | -574.4 | |
| 0.00 | 1.23 | 0.00 | 0.68 | -15.02 | 116.11 | 16.04 | 216.50 | 0.4505 | -840.0 | -737.6 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -15.90 | 114.34 | 14.27 | 212.24 | 0.4461 | -651.0 | -515.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
