SDO HMI 2014-10-07 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.74 | 16.52 | 2.40 | 8.32 | 13.02 | 92.80 | -7.27 | 41.67 | 0.1736 | -43.6 | -135.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-07 10:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.32 | 0.00 | 0.65 | 10.19 | 98.89 | -1.18 | 16.97 | 0.0698 | -892.0 | -749.5 | |
| 0.00 | 2.20 | 0.00 | 1.09 | 10.49 | 98.59 | -1.49 | 19.58 | 0.0764 | -1015.0 | -827.9 | |
| 0.00 | 1.05 | 0.00 | 0.52 | 11.17 | 97.24 | -2.83 | 30.07 | 0.0972 | -835.0 | -570.0 | |
| 0.00 | 1.32 | 0.00 | 0.66 | 10.69 | 97.06 | -3.01 | 34.41 | 0.0918 | -860.0 | -655.0 | |
| 0.00 | 1.32 | 0.00 | 0.66 | 11.93 | 93.89 | -6.19 | 47.27 | 0.1442 | -721.0 | -557.8 | |
| 0.00 | 0.70 | 0.00 | 0.36 | 19.02 | 90.48 | -9.60 | 35.57 | 0.2721 | 373.0 | 264.1 | |
| 1.23 | 7.64 | 0.62 | 3.88 | 13.56 | 89.52 | -10.56 | 54.56 | 0.2196 | 1149.7 | 833.1 | |
| 3.51 | -7.00 | 1.78 | -7.00 | 13.46 | 89.43 | -10.65 | 55.13 | 0.2200 | 1127.6 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 20.77 | 88.29 | -11.79 | 37.31 | 0.3166 | 820.0 | 729.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
