SDO HMI 2014-10-07 12:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.29 | 117.79 | 31.33 | 169.90 | -12.47 | 166.61 | 67.63 | 254.17 | 0.9394 | 258.5 | 18.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-07 12:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.73 | 102.70 | 26.24 | 152.88 | -12.49 | 167.30 | 68.32 | 254.31 | 0.9439 | 454.3 | 35.8 | |
| 0.00 | 1.32 | 0.00 | 1.85 | -12.05 | 166.16 | 67.18 | 254.52 | 0.9369 | 380.0 | 438.4 | |
| 3.77 | 6.50 | 4.27 | 7.35 | -11.65 | 160.74 | 61.76 | 253.71 | 0.9007 | -529.4 | -361.2 | |
| 0.00 | 0.61 | 0.00 | 0.81 | -17.33 | 163.37 | 64.39 | 248.34 | 0.9279 | 412.0 | 360.9 | |
| 0.00 | 0.79 | 0.00 | 0.88 | -12.06 | 160.19 | 61.21 | 253.13 | 0.8974 | -206.0 | -166.8 | |
| 0.00 | 2.63 | 0.00 | 2.89 | -12.05 | 159.73 | 60.75 | 253.03 | 0.8941 | -591.0 | -466.5 | |
| 0.79 | 2.19 | 0.82 | 2.27 | -12.54 | 157.77 | 58.79 | 251.96 | 0.8800 | -589.4 | -521.0 | |
| 0.00 | 1.05 | 0.00 | 0.97 | -13.93 | 153.26 | 54.28 | 249.02 | 0.8460 | 219.0 | 246.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
