SDO HMI 2014-10-07 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.41 | 173.52 | 25.84 | 169.91 | -1.88 | 155.81 | 59.03 | 264.03 | 0.8637 | 737.6 | 217.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-07 16:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.67 | 169.66 | 1.66 | 166.36 | -2.15 | 156.45 | 59.68 | 263.83 | 0.8696 | 233.8 | 217.9 | |
| 23.95 | -1.00 | 23.42 | -1.00 | -1.85 | 155.84 | 59.06 | 264.07 | 0.8639 | 861.9 | 999999 | |
| 0.79 | -1.00 | 0.76 | -1.00 | -2.21 | 155.22 | 58.44 | 263.54 | 0.8590 | 721.2 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.93 | -3.15 | 155.24 | 58.46 | 262.46 | 0.8604 | 300.0 | 305.7 | |
| 0.00 | 1.23 | 0.00 | 1.17 | -3.10 | 154.72 | 57.94 | 262.42 | 0.8557 | 441.0 | 326.1 | |
| 0.00 | 0.79 | 0.00 | 0.70 | -0.60 | 152.55 | 55.77 | 264.97 | 0.8321 | 602.0 | 487.3 | |
| 0.00 | 0.88 | 0.00 | 0.75 | -0.70 | 150.77 | 53.99 | 264.53 | 0.8147 | -454.0 | -431.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
