SDO HMI 2014-10-08 21:03:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 27.45 | 0.00 | 14.73 | 13.85 | 59.55 | -21.25 | 67.33 | 0.3813 | -202.7 | -129.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-08 21:03:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.88 | 0.00 | 0.51 | 14.55 | 49.22 | -31.58 | 72.57 | 0.5333 | 465.0 | 419.7 | |
| 0.00 | 3.24 | 0.00 | 1.82 | 11.95 | 52.68 | -28.11 | 76.46 | 0.4761 | 552.0 | 543.6 | |
| 0.00 | 0.79 | 0.00 | 0.44 | 12.45 | 52.81 | -27.99 | 75.38 | 0.4755 | 685.0 | 509.7 | |
| 0.00 | 0.96 | 0.00 | 0.54 | 12.61 | 53.21 | -27.58 | 74.90 | 0.4699 | 823.0 | 699.7 | |
| 0.00 | 0.96 | 0.00 | 0.54 | 12.19 | 53.45 | -27.35 | 75.70 | 0.4654 | 874.0 | 765.5 | |
| 0.00 | 2.37 | 0.00 | 1.29 | 13.05 | 56.47 | -24.32 | 72.47 | 0.4226 | 752.0 | 583.0 | |
| 0.00 | 0.88 | 0.00 | 0.47 | 12.85 | 57.47 | -23.33 | 72.38 | 0.4068 | 812.0 | 665.7 | |
| 0.00 | 1.40 | 0.00 | 0.76 | 17.44 | 60.11 | -20.69 | 59.36 | 0.3935 | -774.0 | -620.0 | |
| 0.00 | 1.05 | 0.00 | 0.56 | 16.02 | 60.23 | -20.57 | 62.57 | 0.3821 | -661.0 | -514.3 | |
| 0.00 | 2.02 | 0.00 | 1.07 | 14.50 | 60.39 | -20.41 | 66.16 | 0.3707 | -804.0 | -692.4 | |
| 0.00 | 2.02 | 0.00 | 1.07 | 14.08 | 60.80 | -19.99 | 66.88 | 0.3622 | -42.0 | -70.6 | |
| 0.00 | 1.32 | 0.00 | 0.69 | 13.78 | 62.85 | -17.95 | 65.71 | 0.3299 | -773.0 | -614.5 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 14.88 | 63.02 | -17.77 | 62.44 | 0.3343 | -914.0 | -686.2 | |
| 0.00 | 2.63 | 0.00 | 1.38 | 14.02 | 63.27 | -17.53 | 64.56 | 0.3250 | -959.0 | -675.7 | |
| 0.00 | 0.79 | 0.00 | 0.41 | 12.24 | 64.32 | -16.47 | 68.75 | 0.2986 | -687.0 | -559.4 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 12.86 | 64.84 | -15.96 | 66.21 | 0.2943 | -818.0 | -595.8 | |
| 0.00 | 1.23 | 0.00 | 0.64 | 16.59 | 66.89 | -13.91 | 51.77 | 0.2946 | -722.0 | -468.4 | |
| 0.00 | 1.23 | 0.00 | 0.63 | 13.97 | 66.68 | -14.12 | 60.05 | 0.2744 | -726.0 | -693.1 | |
| 0.00 | 1.58 | 0.00 | 0.81 | 14.58 | 66.86 | -13.93 | 57.78 | 0.2767 | -935.0 | -747.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
