SDO HMI 2014-10-09 18:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 53.97 | 343.79 | 48.45 | 309.42 | -20.58 | 18.68 | -50.61 | 119.80 | 0.8358 | 828.1 | 172.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-09 18:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.31 | 0.00 | 1.11 | -19.64 | 20.82 | -48.47 | 119.70 | 0.8139 | 511.0 | 457.3 | |
| 2.10 | 335.91 | 1.82 | 302.53 | -20.49 | 20.17 | -49.12 | 120.35 | 0.8229 | 796.2 | 176.0 | |
| 4.21 | -2.00 | 3.70 | -2.00 | -20.58 | 19.49 | -49.80 | 120.15 | 0.8290 | 954.0 | 999999 | |
| 47.66 | -2.00 | 42.93 | -2.00 | -20.66 | 18.55 | -50.74 | 119.82 | 0.8372 | 931.9 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.75 | -17.66 | 19.52 | -49.77 | 116.87 | 0.8178 | 572.0 | 465.5 | |
| 0.00 | 1.66 | 0.00 | 1.44 | -17.78 | 19.27 | -50.01 | 116.90 | 0.8203 | 551.0 | 424.7 | |
| 0.00 | 0.53 | 0.00 | 0.46 | -17.85 | 18.50 | -50.78 | 116.66 | 0.8274 | 184.0 | 239.5 | |
| 0.00 | 0.61 | 0.00 | 0.55 | -18.10 | 17.85 | -51.44 | 116.67 | 0.8339 | 291.0 | 238.3 | |
| 0.00 | 1.93 | 0.00 | 1.69 | -16.86 | 18.04 | -51.25 | 115.34 | 0.8280 | -637.0 | -536.6 | |
| 0.00 | 0.96 | 0.00 | 0.89 | -17.42 | 16.38 | -52.91 | 115.33 | 0.8442 | -537.0 | -457.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
