SDO HMI 2014-10-10 01:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 61.54 | 364.20 | 50.95 | 302.34 | -20.58 | 18.55 | -46.88 | 121.51 | 0.8038 | 896.0 | 214.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-10 01:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.88 | 350.26 | 0.70 | 290.87 | -20.45 | 20.08 | -45.34 | 122.15 | 0.7894 | 837.8 | 217.3 | |
| 0.00 | 1.05 | 0.00 | 0.82 | -18.45 | 20.80 | -44.63 | 120.21 | 0.7734 | -227.0 | -247.8 | |
| 3.51 | -1.00 | 2.85 | -1.00 | -20.50 | 19.47 | -45.96 | 121.89 | 0.7952 | 992.8 | 999999 | |
| 0.00 | 1.67 | 0.00 | 1.34 | -19.42 | 19.33 | -46.10 | 120.58 | 0.7916 | 612.0 | 485.3 | |
| 55.48 | -1.00 | 46.08 | -1.00 | -20.65 | 18.48 | -46.95 | 121.56 | 0.8047 | 1028.4 | 999999 | |
| 1.67 | 3.42 | 1.32 | 2.72 | -17.78 | 19.36 | -46.07 | 118.70 | 0.7841 | 651.5 | 468.7 | |
| 0.00 | 0.79 | 0.00 | 0.63 | -17.71 | 19.11 | -46.32 | 118.49 | 0.7861 | 416.0 | 347.0 | |
| 0.00 | 1.05 | 0.00 | 0.94 | -23.62 | 16.34 | -49.08 | 123.80 | 0.8353 | 514.0 | 440.2 | |
| 0.00 | 1.84 | 0.00 | 1.65 | -22.41 | 15.84 | -49.58 | 122.25 | 0.8344 | 484.0 | 374.4 | |
| 0.00 | 1.84 | 0.00 | 1.49 | -16.79 | 18.08 | -47.34 | 116.93 | 0.7920 | -656.0 | -592.0 | |
| 0.00 | 1.58 | 0.00 | 1.30 | -17.82 | 17.73 | -47.70 | 117.97 | 0.7995 | 423.0 | 232.4 | |
| 0.00 | 0.70 | 0.00 | 0.58 | -18.00 | 17.52 | -47.90 | 118.08 | 0.8021 | -411.0 | -393.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
