SDO HMI 2014-10-11 03:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.18 | 426.80 | 42.11 | 284.71 | -20.55 | 18.14 | -32.99 | 130.37 | 0.6713 | 1027.4 | 303.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 03:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.88 | 0.00 | 0.57 | -21.29 | 20.58 | -30.56 | 133.35 | 0.6537 | -646.0 | -488.5 | |
| 0.00 | 1.05 | 0.00 | 0.65 | -15.27 | 21.42 | -29.71 | 126.35 | 0.5959 | 722.0 | 557.2 | |
| 0.00 | 0.88 | 0.00 | 0.56 | -18.83 | 20.45 | -30.69 | 130.21 | 0.6348 | 785.0 | 697.9 | |
| 1.23 | 417.33 | 0.81 | 278.44 | -20.34 | 19.07 | -32.06 | 130.88 | 0.6606 | 1219.3 | 307.9 | |
| 0.88 | 2.54 | 0.56 | 1.62 | -17.48 | 19.57 | -31.56 | 127.70 | 0.6332 | 815.6 | 570.4 | |
| 0.00 | 1.49 | 0.00 | 0.96 | -18.48 | 19.19 | -31.95 | 128.67 | 0.6450 | 657.0 | 515.8 | |
| 58.97 | -4.00 | 39.32 | -4.00 | -20.59 | 18.17 | -32.96 | 130.44 | 0.6714 | 1225.5 | 999999 | |
| 2.10 | -4.00 | 1.42 | -4.00 | -20.88 | 17.30 | -33.84 | 130.07 | 0.6822 | 681.3 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.47 | -19.11 | 16.46 | -34.67 | 127.26 | 0.6777 | -446.0 | -422.8 | |
| 0.00 | 1.14 | 0.00 | 0.76 | -13.74 | 14.07 | -37.06 | 118.62 | 0.6692 | -652.0 | -542.2 | |
| 0.00 | 0.79 | 0.00 | 0.68 | -27.07 | 6.09 | -45.04 | 129.53 | 0.8192 | -561.0 | -445.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
