SDO HMI 2014-10-11 06:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 66.95 | 437.96 | 43.80 | 286.92 | -20.53 | 18.11 | -31.38 | 131.69 | 0.6552 | 979.5 | 296.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 06:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.84 | 0.00 | 1.18 | -21.28 | 20.64 | -28.85 | 134.91 | 0.6371 | -513.0 | -372.7 | |
| 0.00 | 0.96 | 0.00 | 0.61 | -18.83 | 20.37 | -29.12 | 131.64 | 0.6185 | 841.0 | 660.6 | |
| 0.00 | 1.66 | 0.00 | 1.04 | -18.34 | 20.32 | -29.17 | 130.96 | 0.6149 | 706.0 | 536.5 | |
| 0.00 | 3.07 | 0.00 | 1.93 | -18.55 | 19.99 | -29.50 | 130.93 | 0.6201 | 829.0 | 693.1 | |
| 1.31 | 418.87 | 0.85 | 274.34 | -20.38 | 19.29 | -30.20 | 132.56 | 0.6425 | 995.2 | 300.1 | |
| 0.00 | 1.14 | 0.00 | 0.73 | -20.04 | 19.36 | -30.13 | 132.21 | 0.6390 | 918.0 | 880.5 | |
| 0.00 | 1.31 | 0.00 | 0.82 | -17.39 | 19.70 | -29.79 | 129.14 | 0.6135 | 803.0 | 595.5 | |
| 3.51 | -5.00 | 2.27 | -5.00 | -20.33 | 19.00 | -30.49 | 132.24 | 0.6449 | 1181.9 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.44 | -18.65 | 19.35 | -30.14 | 130.46 | 0.6275 | 679.0 | 562.8 | |
| 0.00 | 2.37 | 0.00 | 1.50 | -18.46 | 19.24 | -30.25 | 130.12 | 0.6271 | 385.0 | 339.9 | |
| 0.00 | 1.14 | 0.00 | 0.71 | -16.83 | 19.22 | -30.27 | 127.97 | 0.6142 | 655.0 | 485.8 | |
| 62.13 | -5.00 | 40.68 | -5.00 | -20.58 | 18.08 | -31.40 | 131.73 | 0.6560 | 1226.5 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.91 | -16.73 | 16.03 | -33.46 | 125.15 | 0.6480 | -510.0 | -416.9 | |
| 0.00 | 0.70 | 0.00 | 0.51 | -22.63 | 11.34 | -38.15 | 128.91 | 0.7350 | -370.0 | -363.9 | |
| 0.00 | 1.23 | 0.00 | 0.86 | -18.02 | 10.71 | -38.78 | 123.01 | 0.7126 | -475.0 | -374.9 | |
| 0.00 | 0.61 | 0.00 | 0.53 | -29.07 | 5.49 | -44.00 | 132.19 | 0.8217 | -387.0 | -306.4 | |
| 0.00 | 0.96 | 0.00 | 0.81 | -27.14 | 5.96 | -43.52 | 130.46 | 0.8077 | -369.0 | -305.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
