SDO HMI 2014-10-11 09:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 69.12 | 443.42 | 44.44 | 285.52 | -20.55 | 17.99 | -29.86 | 133.07 | 0.6403 | 871.0 | 285.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 09:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.14 | 0.00 | 0.72 | -21.24 | 20.61 | -27.24 | 136.45 | 0.6214 | -288.0 | -310.0 | |
| 0.00 | 1.23 | 0.00 | 0.76 | -18.33 | 20.34 | -27.51 | 132.56 | 0.5975 | 800.0 | 716.2 | |
| 0.00 | 3.24 | 0.00 | 2.01 | -18.48 | 20.03 | -27.82 | 132.43 | 0.6020 | 876.0 | 710.0 | |
| 0.00 | 2.19 | 0.00 | 1.38 | -19.97 | 19.31 | -28.54 | 133.61 | 0.6224 | 735.0 | 660.6 | |
| 0.00 | 0.79 | 0.00 | 0.49 | -18.64 | 19.49 | -28.35 | 132.11 | 0.6089 | 672.0 | 631.4 | |
| 0.00 | 2.80 | 0.00 | 1.75 | -18.52 | 19.30 | -28.55 | 131.77 | 0.6098 | 792.0 | 628.1 | |
| 2.89 | 422.47 | 1.84 | 271.82 | -20.32 | 18.91 | -28.94 | 133.66 | 0.6295 | 1213.9 | 289.6 | |
| 0.00 | 1.31 | 0.00 | 0.81 | -16.79 | 19.25 | -28.60 | 129.44 | 0.5957 | 640.0 | 396.2 | |
| 1.14 | -7.00 | 0.73 | -7.00 | -21.09 | 18.27 | -29.58 | 133.98 | 0.6424 | 470.0 | 999999 | |
| 2.10 | -7.00 | 1.34 | -7.00 | -20.02 | 18.28 | -29.57 | 132.69 | 0.6331 | 1160.5 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.46 | -22.30 | 17.69 | -30.16 | 134.88 | 0.6582 | -313.0 | -244.9 | |
| 62.99 | -7.00 | 40.53 | -7.00 | -20.57 | 18.01 | -29.84 | 133.11 | 0.6404 | 1125.3 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.55 | -18.05 | 18.12 | -29.73 | 130.05 | 0.6182 | -469.0 | -450.6 | |
| 0.00 | 1.49 | 0.00 | 0.99 | -20.91 | 15.00 | -32.84 | 130.89 | 0.6725 | 471.0 | 340.6 | |
| 0.00 | 0.53 | 0.00 | 0.38 | -25.17 | 11.27 | -36.58 | 132.87 | 0.7381 | -268.0 | -333.2 | |
| 0.00 | 1.14 | 0.00 | 0.86 | -26.16 | 10.16 | -37.69 | 133.14 | 0.7543 | -111.0 | -202.6 | |
| 0.00 | 0.79 | 0.00 | 0.60 | -26.45 | 9.96 | -37.89 | 133.31 | 0.7580 | -439.0 | -482.8 | |
| 0.00 | 1.23 | 0.00 | 0.92 | -25.66 | 10.18 | -37.67 | 132.62 | 0.7508 | -583.0 | -411.6 | |
| 0.00 | 1.49 | 0.00 | 1.02 | -18.01 | 10.76 | -37.09 | 124.11 | 0.6951 | -483.0 | -404.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
