SDO HMI 2014-10-11 11:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 65.08 | 461.97 | 41.36 | 294.22 | -20.53 | 18.02 | -28.73 | 134.13 | 0.6292 | 826.4 | 278.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 11:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.66 | -21.32 | 20.59 | -26.17 | 137.65 | 0.6121 | -675.0 | -545.2 | |
| 0.00 | 0.79 | 0.00 | 0.50 | -21.80 | 20.46 | -26.30 | 138.08 | 0.6179 | -664.0 | -590.9 | |
| 0.00 | 1.14 | 0.00 | 0.70 | -20.22 | 20.62 | -26.14 | 136.36 | 0.6012 | 682.0 | 461.8 | |
| 0.00 | 1.58 | 0.00 | 0.99 | -21.51 | 20.15 | -26.60 | 137.42 | 0.6180 | -90.0 | -183.4 | |
| 0.00 | 2.28 | 0.00 | 1.39 | -18.35 | 20.31 | -26.45 | 133.68 | 0.5867 | 815.0 | 639.4 | |
| 0.00 | 3.07 | 0.00 | 1.88 | -18.79 | 20.05 | -26.70 | 133.98 | 0.5933 | 653.0 | 617.4 | |
| 0.00 | 3.77 | 0.00 | 2.31 | -18.43 | 20.05 | -26.71 | 133.50 | 0.5901 | 872.0 | 736.0 | |
| 0.79 | 436.02 | 0.49 | 277.56 | -20.42 | 19.22 | -27.54 | 135.15 | 0.6166 | 943.7 | 283.2 | |
| 0.00 | 1.49 | 0.00 | 0.93 | -19.92 | 19.28 | -27.48 | 134.60 | 0.6115 | 897.0 | 776.8 | |
| 0.79 | 2.54 | 0.49 | 1.57 | -18.56 | 19.42 | -27.33 | 133.02 | 0.5977 | 715.3 | 591.7 | |
| 2.63 | -8.00 | 1.65 | -8.00 | -20.34 | 18.87 | -27.88 | 134.70 | 0.6192 | 1231.2 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.70 | -17.79 | 18.98 | -27.77 | 131.59 | 0.5954 | 644.0 | 559.7 | |
| 60.87 | -8.00 | 38.73 | -8.00 | -20.58 | 18.02 | -28.73 | 134.17 | 0.6297 | 1068.8 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.58 | -20.86 | 14.92 | -31.84 | 131.67 | 0.6622 | 470.0 | 328.5 | |
| 0.00 | 0.79 | 0.00 | 0.59 | -26.25 | 9.88 | -36.88 | 133.81 | 0.7481 | -441.0 | -468.6 | |
| 0.00 | 1.84 | 0.00 | 1.24 | -18.07 | 10.87 | -35.88 | 125.03 | 0.6828 | -582.0 | -440.8 | |
| 0.00 | 2.01 | 0.00 | 1.36 | -17.88 | 10.76 | -36.00 | 124.71 | 0.6827 | -552.0 | -462.0 | |
| 0.00 | 1.58 | 0.00 | 1.26 | -27.20 | 5.90 | -40.85 | 132.13 | 0.7867 | -525.0 | -380.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
