SDO HMI 2014-10-11 17:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.63 | 459.39 | 42.34 | 284.06 | -20.60 | 17.85 | -25.61 | 137.41 | 0.5997 | 950.7 | 327.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 17:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.23 | 0.00 | 0.75 | -21.88 | 20.28 | -23.17 | 141.65 | 0.5907 | -573.0 | -521.7 | |
| 0.53 | 2.01 | 0.31 | 1.20 | -18.23 | 20.10 | -23.35 | 137.02 | 0.5544 | 972.3 | 871.6 | |
| 0.00 | 1.14 | 0.00 | 0.68 | -18.63 | 20.01 | -23.45 | 137.42 | 0.5594 | 848.0 | 606.4 | |
| 0.00 | 1.23 | 0.00 | 0.73 | -18.41 | 19.70 | -23.76 | 136.77 | 0.5603 | 807.0 | 694.0 | |
| 0.53 | 4.29 | 0.32 | 2.59 | -19.55 | 19.35 | -24.11 | 137.79 | 0.5752 | 959.0 | 710.0 | |
| 0.00 | 1.05 | 0.00 | 0.63 | -17.77 | 19.41 | -24.04 | 135.60 | 0.5567 | 632.0 | 546.2 | |
| 0.00 | 1.31 | 0.00 | 0.79 | -18.47 | 19.10 | -24.36 | 136.15 | 0.5668 | 451.0 | 343.5 | |
| 1.58 | 438.46 | 0.98 | 270.72 | -21.11 | 17.95 | -25.51 | 138.12 | 0.6039 | 548.9 | 342.2 | |
| 65.99 | -8.00 | 40.73 | -8.00 | -20.58 | 17.98 | -25.48 | 137.50 | 0.5984 | 1278.5 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.90 | -13.43 | 14.70 | -28.75 | 124.53 | 0.5701 | -722.0 | -520.5 | |
| 0.00 | 0.35 | 0.00 | 0.21 | -13.27 | 14.30 | -29.15 | 123.92 | 0.5735 | -684.0 | -637.5 | |
| 0.00 | 2.19 | 0.00 | 1.56 | -26.26 | 9.87 | -33.59 | 136.33 | 0.7207 | -723.0 | -583.9 | |
| 0.00 | 1.14 | 0.00 | 0.81 | -26.52 | 9.66 | -33.79 | 136.44 | 0.7245 | -444.0 | -367.8 | |
| 0.00 | 0.96 | 0.00 | 0.62 | -17.96 | 10.82 | -32.63 | 127.38 | 0.6479 | -526.0 | -393.9 | |
| 0.00 | 1.14 | 0.00 | 0.88 | -29.32 | 6.39 | -37.07 | 136.87 | 0.7710 | -144.0 | -233.8 | |
| 0.00 | 1.40 | 0.00 | 0.99 | -23.30 | 7.97 | -35.48 | 131.59 | 0.7151 | -512.0 | -421.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
