SDO HMI 2014-10-11 20:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 58.63 | 487.11 | 35.71 | 297.29 | -20.64 | 17.79 | -24.01 | 139.26 | 0.5852 | 995.2 | 345.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-11 20:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.96 | 0.00 | 0.57 | -20.22 | 20.66 | -21.14 | 142.24 | 0.5548 | 602.0 | 530.3 | |
| 0.00 | 1.14 | 0.00 | 0.68 | -21.34 | 20.32 | -21.48 | 143.10 | 0.5702 | -495.0 | -428.2 | |
| 0.00 | 3.15 | 0.00 | 1.85 | -18.16 | 20.09 | -21.71 | 138.98 | 0.5376 | 933.0 | 772.2 | |
| 0.00 | 1.05 | 0.00 | 0.62 | -18.59 | 20.04 | -21.76 | 139.46 | 0.5428 | 866.0 | 688.0 | |
| 0.00 | 1.05 | 0.00 | 0.62 | -18.37 | 19.86 | -21.94 | 138.95 | 0.5420 | 938.0 | 731.7 | |
| 0.00 | 2.45 | 0.00 | 1.46 | -19.31 | 19.35 | -22.45 | 139.49 | 0.5569 | 944.0 | 759.8 | |
| 58.63 | 469.25 | 35.71 | 285.96 | -20.60 | 17.90 | -23.90 | 139.32 | 0.5839 | 1366.7 | 355.2 | |
| 0.00 | 0.88 | 0.00 | 0.55 | -20.76 | 14.53 | -27.26 | 135.84 | 0.6171 | 646.0 | 561.6 | |
| 0.00 | 0.88 | 0.00 | 0.57 | -22.22 | 11.87 | -29.93 | 134.98 | 0.6553 | -553.0 | -506.9 | |
| 0.00 | 0.44 | 0.00 | 0.29 | -21.65 | 11.18 | -30.62 | 133.68 | 0.6569 | -601.0 | -505.0 | |
| 0.00 | 1.66 | 0.00 | 1.16 | -26.30 | 9.87 | -31.93 | 137.74 | 0.7073 | -704.0 | -633.9 | |
| 0.00 | 1.31 | 0.00 | 0.92 | -26.49 | 9.65 | -32.14 | 137.76 | 0.7106 | -555.0 | -440.5 | |
| 0.00 | 1.14 | 0.00 | 0.73 | -18.19 | 10.75 | -31.05 | 129.03 | 0.6330 | -604.0 | -492.2 | |
| 0.00 | 1.31 | 0.00 | 0.97 | -26.85 | 5.72 | -36.08 | 135.03 | 0.7457 | -249.0 | -219.7 | |
| 0.00 | 0.44 | 0.00 | 0.34 | -29.10 | 4.65 | -37.15 | 136.60 | 0.7701 | -501.0 | -432.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
