SDO HMI 2014-10-13 10:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 74.38 | 499.93 | 41.32 | 277.91 | -20.71 | 17.47 | -3.44 | 172.88 | 0.4548 | 965.6 | 350.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-13 10:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.23 | 4.73 | 0.66 | 2.56 | -18.06 | 20.55 | -0.37 | 179.13 | 0.4092 | 1060.2 | 846.2 | |
| 0.00 | 1.31 | 0.00 | 0.73 | -21.62 | 19.76 | -1.16 | 177.68 | 0.4657 | -791.0 | -700.2 | |
| 0.00 | 1.05 | 0.00 | 0.57 | -18.78 | 19.69 | -1.23 | 177.23 | 0.4212 | 757.0 | 600.3 | |
| 0.00 | 1.75 | 0.00 | 0.95 | -18.38 | 19.66 | -1.26 | 177.12 | 0.4149 | 768.0 | 689.5 | |
| 0.00 | 1.84 | 0.00 | 0.99 | -17.63 | 19.64 | -1.28 | 176.96 | 0.4029 | 839.0 | 585.2 | |
| 0.00 | 1.23 | 0.00 | 0.67 | -18.22 | 19.54 | -1.38 | 176.81 | 0.4124 | 942.0 | 712.9 | |
| 0.00 | 1.31 | 0.00 | 0.71 | -18.32 | 18.40 | -2.52 | 174.22 | 0.4155 | 935.0 | 714.5 | |
| 0.00 | 1.58 | 0.00 | 0.87 | -19.58 | 18.13 | -2.79 | 173.93 | 0.4357 | 775.0 | 585.4 | |
| 72.54 | 471.55 | 40.33 | 262.34 | -20.81 | 17.49 | -3.42 | 172.94 | 0.4561 | 1323.9 | 367.0 | |
| 0.00 | 2.10 | 0.00 | 1.15 | -18.89 | 17.38 | -3.54 | 172.09 | 0.4263 | 459.0 | 330.8 | |
| 0.61 | 1.93 | 0.33 | 1.05 | -18.27 | 16.26 | -4.66 | 169.35 | 0.4195 | -831.7 | -736.6 | |
| 0.00 | 1.23 | 0.00 | 0.68 | -20.93 | 15.66 | -5.26 | 169.28 | 0.4622 | 685.0 | 447.7 | |
| 0.00 | 2.36 | 0.00 | 1.29 | -18.14 | 15.72 | -5.20 | 168.10 | 0.4192 | -891.0 | -585.8 | |
| 0.00 | 1.23 | 0.00 | 0.67 | -18.41 | 15.24 | -5.68 | 167.18 | 0.4249 | -805.0 | -608.8 | |
| 0.00 | 1.05 | 0.00 | 0.63 | -26.51 | 10.76 | -10.16 | 163.59 | 0.5608 | -594.0 | -451.4 | |
| 0.00 | 2.54 | 0.00 | 1.40 | -18.17 | 11.28 | -9.64 | 158.68 | 0.4396 | -936.0 | -773.2 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -22.07 | 10.99 | -9.93 | 161.19 | 0.4974 | -751.0 | -593.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
