SDO HMI 2014-10-14 14:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 72.01 | 455.98 | 40.90 | 259.00 | -20.95 | 17.23 | 11.70 | 202.83 | 0.4903 | 962.2 | 359.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-14 14:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.92 | 0.00 | 1.08 | -17.66 | 20.23 | 14.69 | 211.35 | 0.4664 | 673.0 | 592.3 | |
| 0.00 | 1.22 | 0.00 | 0.69 | -18.01 | 19.96 | 14.43 | 210.50 | 0.4689 | 739.0 | 711.6 | |
| 0.00 | 1.05 | 0.00 | 0.59 | -17.71 | 19.84 | 14.31 | 210.62 | 0.4641 | 794.0 | 643.8 | |
| 0.00 | 0.61 | 0.00 | 0.34 | -18.96 | 18.77 | 13.24 | 207.39 | 0.4728 | 853.0 | 748.1 | |
| 0.00 | 0.70 | 0.00 | 0.39 | -18.49 | 18.15 | 12.62 | 206.77 | 0.4619 | -656.0 | -542.4 | |
| 0.00 | 1.31 | 0.00 | 0.74 | -19.89 | 17.61 | 12.08 | 204.43 | 0.4777 | 256.0 | 202.0 | |
| 29.28 | 436.13 | 16.67 | 247.85 | -21.06 | 17.67 | 12.14 | 203.49 | 0.4942 | 1217.7 | 374.5 | |
| 0.87 | 2.19 | 0.49 | 1.22 | -19.09 | 17.16 | 11.63 | 204.37 | 0.4637 | 951.6 | 761.9 | |
| 41.86 | -7.00 | 23.74 | -7.00 | -20.95 | 17.07 | 11.54 | 202.56 | 0.4891 | 1340.0 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.55 | -22.33 | 17.15 | 11.62 | 201.57 | 0.5088 | -211.0 | -153.0 | |
| 0.00 | 1.14 | 0.00 | 0.60 | -13.54 | 14.46 | 8.93 | 204.46 | 0.3661 | -835.0 | -677.7 | |
| 0.00 | 1.14 | 0.00 | 0.63 | -18.84 | 14.64 | 9.11 | 199.74 | 0.4453 | -667.0 | -681.6 | |
| 0.00 | 1.75 | 0.00 | 0.98 | -20.93 | 14.63 | 9.10 | 198.16 | 0.4759 | 817.0 | 728.5 | |
| 0.00 | 0.96 | 0.00 | 0.54 | -20.73 | 14.46 | 8.92 | 197.98 | 0.4721 | 625.0 | 530.4 | |
| 0.00 | 2.19 | 0.00 | 1.20 | -18.88 | 11.20 | 5.67 | 192.58 | 0.4310 | -743.0 | -684.0 | |
| 0.00 | 1.40 | 0.00 | 0.81 | -25.45 | 10.00 | 4.47 | 187.71 | 0.5270 | -637.0 | -494.6 | |
| 0.00 | 1.31 | 0.00 | 0.79 | -28.39 | 4.91 | -0.62 | 179.03 | 0.5658 | -748.0 | -613.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
