SDO HMI 2014-10-15 00:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 69.92 | 462.78 | 40.74 | 269.78 | -21.11 | 17.03 | 17.01 | 211.24 | 0.5289 | 885.9 | 362.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-15 00:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.31 | 0.00 | 0.76 | -17.99 | 20.34 | 20.33 | 219.64 | 0.5201 | 752.0 | 589.4 | |
| 31.55 | 441.62 | 18.45 | 257.54 | -21.19 | 17.54 | 17.53 | 211.91 | 0.5334 | 1158.7 | 382.5 | |
| 0.00 | 1.31 | 0.00 | 0.75 | -18.72 | 16.97 | 16.95 | 213.81 | 0.4983 | -585.0 | -366.7 | |
| 36.27 | -2.00 | 21.09 | -2.00 | -20.94 | 16.98 | 16.96 | 211.34 | 0.5259 | 1365.4 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.27 | -21.71 | 14.79 | 14.78 | 207.24 | 0.5198 | 821.0 | 622.2 | |
| 0.00 | 1.14 | 0.00 | 0.65 | -21.31 | 14.68 | 14.67 | 207.45 | 0.5138 | 809.0 | 666.5 | |
| 0.00 | 0.44 | 0.00 | 0.26 | -23.31 | 14.66 | 14.65 | 205.59 | 0.5398 | -613.0 | -439.0 | |
| 0.44 | 1.66 | 0.25 | 0.97 | -22.61 | 14.05 | 14.04 | 205.26 | 0.5267 | -832.8 | -720.4 | |
| 1.66 | 6.21 | 0.95 | 3.55 | -21.04 | 13.73 | 13.72 | 206.17 | 0.5039 | 846.4 | 445.8 | |
| 0.00 | 1.49 | 0.00 | 0.86 | -21.81 | 13.31 | 13.29 | 204.78 | 0.5113 | -758.0 | -559.6 | |
| 0.00 | 1.05 | 0.00 | 0.58 | -18.72 | 11.17 | 11.15 | 203.83 | 0.4554 | -814.0 | -626.8 | |
| 0.00 | 0.87 | 0.00 | 0.49 | -21.65 | 7.66 | 7.65 | 195.00 | 0.4800 | -691.0 | -620.1 | |
| 0.00 | 0.61 | 0.00 | 0.37 | -28.20 | 4.42 | 4.41 | 186.89 | 0.5667 | -771.0 | -564.9 | |
| 0.00 | 1.40 | 0.00 | 0.84 | -28.45 | 4.13 | 4.11 | 186.38 | 0.5698 | -581.0 | -494.9 | |
| 0.00 | 1.49 | 0.00 | 0.89 | -28.13 | 4.08 | 4.07 | 186.38 | 0.5650 | -787.0 | -638.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
