SDO HMI 2014-10-15 15:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 65.94 | 411.90 | 40.72 | 254.48 | -21.14 | 17.04 | 25.25 | 221.83 | 0.5989 | 1094.2 | 328.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-15 15:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.44 | 0.00 | 0.26 | -17.11 | 16.86 | 25.07 | 226.77 | 0.5580 | -619.0 | -452.4 | |
| 32.05 | 408.23 | 19.86 | 252.25 | -21.21 | 17.40 | 25.61 | 222.13 | 0.6029 | 1128.6 | 331.8 | |
| 33.10 | -2.00 | 20.37 | -2.00 | -21.02 | 16.79 | 25.00 | 221.70 | 0.5953 | 1342.4 | 999999 | |
| 0.79 | -2.00 | 0.49 | -2.00 | -21.55 | 16.75 | 24.96 | 221.02 | 0.6002 | 702.9 | 999999 | |
| 0.00 | 1.48 | 0.00 | 0.91 | -22.33 | 14.56 | 22.77 | 217.61 | 0.5888 | 699.0 | 547.1 | |
| 0.00 | 1.14 | 0.00 | 0.68 | -21.09 | 13.07 | 21.28 | 217.19 | 0.5625 | -581.0 | -497.5 | |
| 0.00 | 0.61 | 0.00 | 0.38 | -28.86 | 4.00 | 12.20 | 198.07 | 0.5990 | -275.0 | -230.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
