SDO HMI 2014-10-16 20:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56.37 | 345.68 | 41.93 | 256.49 | -21.13 | 16.41 | 40.57 | 234.68 | 0.7458 | 791.0 | 277.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-16 20:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.17 | 319.59 | 18.09 | 238.01 | -21.19 | 16.98 | 41.14 | 234.96 | 0.7515 | 995.1 | 298.8 | |
| 0.00 | 1.40 | 0.00 | 1.02 | -19.80 | 16.36 | 40.52 | 236.23 | 0.7377 | 178.0 | 203.1 | |
| 0.00 | 1.13 | 0.00 | 0.81 | -18.09 | 15.78 | 39.94 | 237.95 | 0.7223 | -333.0 | -286.2 | |
| 25.83 | -1.00 | 19.11 | -1.00 | -20.99 | 16.40 | 40.56 | 234.84 | 0.7449 | 1270.1 | 999999 | |
| 5.93 | -1.00 | 4.41 | -1.00 | -21.46 | 16.47 | 40.63 | 234.34 | 0.7483 | 958.0 | 999999 | |
| 0.44 | 11.96 | 0.32 | 8.65 | -21.37 | 14.69 | 38.85 | 233.30 | 0.7308 | 660.0 | 430.7 | |
| 0.00 | 0.96 | 0.00 | 0.70 | -21.92 | 14.49 | 38.65 | 232.52 | 0.7324 | 236.0 | 193.6 | |
| 0.00 | 1.57 | 0.00 | 1.13 | -22.42 | 13.87 | 38.03 | 231.53 | 0.7297 | -395.0 | -378.9 | |
| 0.00 | 1.22 | 0.00 | 0.86 | -21.45 | 12.39 | 36.55 | 231.63 | 0.7094 | -302.0 | -373.4 | |
| 0.00 | 1.92 | 0.00 | 1.25 | -15.36 | 10.36 | 34.52 | 237.86 | 0.6476 | -547.0 | -480.4 | |
| 0.00 | 0.96 | 0.00 | 0.62 | -14.97 | 10.25 | 34.41 | 238.31 | 0.6439 | -692.0 | -580.1 | |
| 0.00 | 0.87 | 0.00 | 0.62 | -24.32 | 11.30 | 35.46 | 227.51 | 0.7193 | -233.0 | -248.9 | |
| 0.00 | 0.87 | 0.00 | 0.62 | -25.59 | 10.55 | 34.71 | 225.53 | 0.7220 | -556.0 | -455.6 | |
| 0.00 | 0.96 | 0.00 | 0.65 | -21.49 | 9.34 | 33.50 | 229.25 | 0.6802 | -361.0 | -383.0 | |
| 0.00 | 1.48 | 0.00 | 1.02 | -23.26 | 9.55 | 33.71 | 227.35 | 0.6955 | -560.0 | -380.9 | |
| 0.00 | 0.79 | 0.00 | 0.53 | -26.94 | 4.87 | 29.02 | 219.27 | 0.6856 | -351.0 | -265.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
