SDO HMI 2014-10-17 00:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 51.24 | 332.09 | 39.50 | 255.54 | -21.13 | 16.50 | 42.87 | 236.04 | 0.7671 | 781.4 | 284.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-17 00:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.48 | 318.82 | 18.22 | 245.89 | -21.20 | 16.96 | 43.33 | 236.23 | 0.7718 | 842.8 | 299.5 | |
| 22.00 | -1.00 | 16.86 | -1.00 | -21.02 | 16.32 | 42.69 | 236.08 | 0.7650 | 1181.4 | 999999 | |
| 4.89 | -1.00 | 3.77 | -1.00 | -21.46 | 16.44 | 42.80 | 235.63 | 0.7684 | 854.1 | 999999 | |
| 0.52 | 1.57 | 0.39 | 1.17 | -21.33 | 14.57 | 40.94 | 234.69 | 0.7503 | 655.0 | 581.5 | |
| 0.00 | 1.83 | 0.00 | 1.40 | -22.74 | 15.07 | 41.44 | 233.37 | 0.7629 | 393.0 | 321.1 | |
| 0.00 | 0.87 | 0.00 | 0.66 | -21.98 | 14.80 | 41.16 | 234.07 | 0.7561 | 252.0 | 402.0 | |
| 0.00 | 1.48 | 0.00 | 1.11 | -21.54 | 14.35 | 40.72 | 234.30 | 0.7495 | 348.0 | 333.5 | |
| 0.35 | 1.66 | 0.26 | 1.23 | -22.14 | 13.79 | 40.16 | 233.26 | 0.7477 | -448.5 | -381.1 | |
| 0.00 | 1.75 | 0.00 | 1.31 | -22.65 | 13.84 | 40.20 | 232.70 | 0.7512 | -559.0 | -423.0 | |
| 0.00 | 1.66 | 0.00 | 1.10 | -15.03 | 10.35 | 36.72 | 239.83 | 0.6702 | -557.0 | -434.5 | |
| 0.00 | 1.40 | 0.00 | 0.90 | -13.34 | 8.59 | 34.96 | 240.97 | 0.6400 | -295.0 | -408.4 | |
| 0.00 | 1.05 | 0.00 | 0.77 | -26.18 | 10.28 | 36.64 | 226.34 | 0.7427 | -525.0 | -455.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
