SDO HMI 2014-10-17 16:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 10.72 | 0.00 | 6.36 | 14.80 | 356.32 | 31.46 | 290.81 | 0.5362 | -391.2 | -347.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-17 16:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.57 | 0.00 | 1.02 | 11.91 | 5.53 | 40.67 | 281.68 | 0.6535 | -648.0 | -490.7 | |
| 0.00 | 1.05 | 0.00 | 0.67 | 13.52 | 4.40 | 39.54 | 284.36 | 0.6412 | -592.0 | -491.4 | |
| 0.00 | 1.22 | 0.00 | 0.75 | 14.30 | 0.53 | 35.67 | 286.54 | 0.5917 | -688.0 | -571.4 | |
| 0.00 | 1.22 | 0.00 | 0.74 | 13.95 | 359.83 | 34.97 | 286.15 | 0.5813 | -786.0 | -651.6 | |
| 0.00 | 1.13 | 0.00 | 0.68 | 15.36 | 357.95 | 33.09 | 289.22 | 0.5597 | -827.0 | -647.9 | |
| 0.00 | 1.13 | 0.00 | 0.68 | 15.84 | 358.04 | 33.18 | 290.02 | 0.5625 | -825.0 | -653.8 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 16.01 | 347.02 | 22.16 | 297.19 | 0.4094 | 842.0 | 732.6 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 15.25 | 343.47 | 18.61 | 299.08 | 0.3538 | 803.0 | 620.3 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 19.10 | 341.49 | 16.63 | 311.10 | 0.3604 | -800.0 | -563.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
