SDO HMI 2014-10-17 19:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.46 | 230.26 | 36.53 | 218.86 | -21.17 | 16.24 | 53.03 | 240.88 | 0.8549 | 779.3 | 214.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-17 19:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.83 | 0.00 | 1.80 | -17.56 | 18.97 | 55.77 | 245.85 | 0.8658 | 422.0 | 336.4 | |
| 0.00 | 0.26 | 0.00 | 0.24 | -17.57 | 17.11 | 53.90 | 245.20 | 0.8507 | 443.0 | 420.0 | |
| 19.01 | 223.46 | 18.21 | 212.77 | -21.24 | 16.61 | 53.41 | 240.96 | 0.8580 | 688.8 | 216.7 | |
| 18.67 | -3.00 | 17.61 | -3.00 | -21.06 | 16.04 | 52.83 | 240.93 | 0.8529 | 1143.7 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.63 | -21.30 | 13.76 | 50.56 | 239.72 | 0.8353 | 576.0 | 495.2 | |
| 0.78 | 1.83 | 0.71 | 1.67 | -22.25 | 13.97 | 50.77 | 238.77 | 0.8406 | 460.8 | 369.3 | |
| 0.00 | 0.26 | 0.00 | 0.24 | -22.64 | 13.51 | 50.30 | 238.13 | 0.8383 | -389.0 | -412.3 | |
| 0.00 | 0.61 | 0.00 | 0.48 | -27.05 | 3.82 | 40.62 | 228.14 | 0.7807 | -401.0 | -362.9 | |
| 0.00 | 1.31 | 0.00 | 1.03 | -27.28 | 3.66 | 40.45 | 227.79 | 0.7809 | -520.0 | -422.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
