SDO HMI 2014-10-21 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 62.91 | 396.48 | 44.35 | 278.64 | -8.92 | 321.60 | 42.92 | 251.68 | 0.7108 | 697.6 | 279.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-21 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.26 | 364.85 | 0.19 | 257.59 | -9.11 | 322.58 | 43.90 | 251.84 | 0.7229 | 330.0 | 323.2 | |
| 2.44 | -1.00 | 1.74 | -1.00 | -8.94 | 322.47 | 43.79 | 252.01 | 0.7211 | 567.1 | 999999 | |
| 58.21 | -1.00 | 41.03 | -1.00 | -8.84 | 321.87 | 43.19 | 251.91 | 0.7138 | 1119.5 | 999999 | |
| 1.39 | -1.00 | 0.98 | -1.00 | -9.43 | 321.46 | 42.78 | 250.95 | 0.7112 | 930.8 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.49 | -10.52 | 321.59 | 42.92 | 249.56 | 0.7169 | 293.0 | 293.4 | |
| 0.00 | 1.48 | 0.00 | 1.02 | -9.07 | 320.22 | 41.54 | 250.91 | 0.6953 | 682.0 | 534.5 | |
| 0.00 | 4.27 | 0.00 | 2.92 | -8.75 | 320.05 | 41.38 | 251.28 | 0.6921 | 819.0 | 697.6 | |
| 0.00 | 3.14 | 0.00 | 2.20 | -12.36 | 320.24 | 41.56 | 246.49 | 0.7091 | 724.0 | 505.5 | |
| 0.00 | 2.09 | 0.00 | 1.41 | -8.03 | 319.28 | 40.60 | 251.96 | 0.6801 | -595.0 | -450.5 | |
| 0.00 | 0.87 | 0.00 | 0.59 | -8.36 | 319.16 | 40.48 | 251.44 | 0.6799 | -515.0 | -422.9 | |
| 0.61 | 4.36 | 0.41 | 2.95 | -10.51 | 318.59 | 39.91 | 248.18 | 0.6819 | -635.3 | -464.8 | |
| 0.00 | 1.74 | 0.00 | 1.17 | -10.18 | 318.34 | 39.66 | 248.50 | 0.6775 | -599.0 | -569.6 | |
| 0.00 | 0.44 | 0.00 | 0.29 | -8.82 | 317.29 | 38.62 | 249.92 | 0.6590 | -655.0 | -581.8 | |
| 0.00 | 2.79 | 0.00 | 1.82 | -8.98 | 316.89 | 38.21 | 249.49 | 0.6546 | -753.0 | -627.3 | |
| 0.00 | 1.92 | 0.00 | 1.25 | -9.29 | 316.85 | 38.17 | 249.03 | 0.6555 | -533.0 | -452.5 | |
| 0.00 | 0.87 | 0.00 | 0.56 | -9.58 | 316.08 | 37.40 | 248.20 | 0.6474 | -610.0 | -507.9 | |
| 0.00 | 1.57 | 0.00 | 1.00 | -9.74 | 315.03 | 36.36 | 247.41 | 0.6352 | -598.0 | -533.1 | |
| 0.00 | 2.61 | 0.00 | 1.65 | -9.49 | 314.03 | 35.36 | 247.19 | 0.6214 | -725.0 | -689.7 | |
| 0.00 | 1.39 | 0.00 | 0.87 | -9.02 | 313.79 | 35.12 | 247.77 | 0.6160 | -791.0 | -567.6 | |
| 0.00 | 1.39 | 0.00 | 0.86 | -7.19 | 312.84 | 34.17 | 250.08 | 0.5949 | -675.0 | -522.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
