SDO HMI 2014-10-22 01:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 57.64 | 293.84 | 51.84 | 263.75 | -8.93 | 321.94 | 54.81 | 255.59 | 0.8357 | 687.6 | 234.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-22 01:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 57.38 | 286.20 | 51.61 | 257.54 | -8.91 | 322.06 | 54.93 | 255.64 | 0.8368 | 792.0 | 244.2 | |
| 0.26 | -1.00 | 0.23 | -1.00 | -9.26 | 321.46 | 54.32 | 255.07 | 0.8319 | 810.7 | 999999 | |
| 0.00 | 0.61 | 0.00 | 0.53 | -9.23 | 320.62 | 53.49 | 254.88 | 0.8240 | 626.0 | 564.0 | |
| 0.00 | 1.04 | 0.00 | 0.90 | -8.60 | 320.44 | 53.30 | 255.58 | 0.8208 | 532.0 | 455.7 | |
| 0.00 | 0.61 | 0.00 | 0.54 | -11.08 | 321.02 | 53.89 | 252.82 | 0.8320 | 501.0 | 400.3 | |
| 0.00 | 1.04 | 0.00 | 0.88 | -10.71 | 319.05 | 51.92 | 252.67 | 0.8124 | -225.0 | -185.0 | |
| 0.00 | 1.04 | 0.00 | 0.88 | -10.54 | 318.91 | 51.78 | 252.82 | 0.8107 | -209.0 | -216.8 | |
| 0.00 | 0.87 | 0.00 | 0.66 | -8.62 | 314.45 | 47.32 | 253.77 | 0.7593 | -503.0 | -427.2 | |
| 0.00 | 1.04 | 0.00 | 0.79 | -9.37 | 314.22 | 47.09 | 252.74 | 0.7590 | -358.0 | -406.0 | |
| 0.00 | 1.39 | 0.00 | 1.03 | -7.65 | 313.37 | 46.24 | 254.66 | 0.7446 | -406.0 | -426.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
