SDO HMI 2014-10-22 22:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.32 | 209.57 | 46.20 | 273.61 | -8.95 | 321.99 | 66.39 | 258.07 | 0.9267 | 593.9 | 196.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-22 22:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.89 | 200.26 | 45.69 | 262.41 | -8.89 | 322.09 | 66.49 | 258.15 | 0.9273 | 658.4 | 200.6 | |
| 0.00 | 1.04 | 0.00 | 1.41 | -10.49 | 322.49 | 66.89 | 256.52 | 0.9316 | 218.0 | 191.2 | |
| 0.00 | 1.48 | 0.00 | 1.82 | -10.03 | 320.28 | 64.69 | 256.60 | 0.9168 | 485.0 | 437.0 | |
| 0.00 | 0.78 | 0.00 | 0.93 | -10.13 | 319.34 | 63.74 | 256.31 | 0.9104 | 531.0 | 472.9 | |
| 0.00 | 2.09 | 0.00 | 2.45 | -10.23 | 319.03 | 63.43 | 256.14 | 0.9084 | 309.0 | 226.6 | |
| 0.00 | 1.48 | 0.00 | 1.76 | -10.98 | 319.25 | 63.65 | 255.36 | 0.9109 | -272.0 | -235.4 | |
| 0.43 | 1.74 | 0.51 | 2.02 | -10.05 | 318.76 | 63.16 | 256.28 | 0.9062 | -247.2 | -163.1 | |
| 0.00 | 0.70 | 0.00 | 0.81 | -10.23 | 318.69 | 63.09 | 256.07 | 0.9059 | -225.0 | -143.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
