SDO HMI 2014-10-23 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.03 | 185.66 | 45.63 | 281.78 | -8.92 | 322.02 | 69.72 | 258.68 | 0.9464 | 552.0 | 153.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-23 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.59 | 181.48 | 45.05 | 276.43 | -8.89 | 322.10 | 69.80 | 258.72 | 0.9469 | 595.9 | 159.6 | |
| 0.00 | 1.13 | 0.00 | 1.54 | -11.16 | 319.28 | 66.98 | 255.84 | 0.9328 | -226.0 | -179.6 | |
| 0.44 | 1.83 | 0.58 | 2.42 | -10.47 | 318.74 | 66.44 | 256.48 | 0.9287 | 73.8 | 44.0 | |
| 0.00 | 1.22 | 0.00 | 1.39 | -9.12 | 315.10 | 62.80 | 257.24 | 0.9023 | -369.0 | -360.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
