SDO HMI 2014-10-27 04:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.81 | 52.89 | 8.84 | 33.96 | -2.97 | 160.74 | -38.80 | 100.64 | 0.6389 | 786.9 | 484.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-27 04:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.13 | 0.00 | 0.69 | 1.15 | 163.80 | -35.75 | 94.79 | 0.5883 | 704.0 | 575.0 | |
| 0.00 | 0.96 | 0.00 | 0.60 | -1.66 | 162.19 | -37.36 | 99.02 | 0.6164 | 596.0 | 395.1 | |
| 13.81 | 46.72 | 8.84 | 29.87 | -3.04 | 161.00 | -38.54 | 100.84 | 0.6359 | 1039.8 | 521.6 | |
| 0.00 | 1.13 | 0.00 | 0.73 | -0.71 | 160.34 | -39.21 | 97.04 | 0.6392 | 424.0 | 401.1 | |
| 0.00 | 0.69 | 0.00 | 0.46 | -4.38 | 159.61 | -39.93 | 102.43 | 0.6577 | 599.0 | 524.1 | |
| 0.00 | 1.13 | 0.00 | 0.74 | -4.67 | 159.32 | -40.23 | 102.76 | 0.6623 | 644.0 | 507.2 | |
| 0.00 | 1.13 | 0.00 | 0.87 | -4.41 | 150.51 | -49.03 | 99.95 | 0.7666 | -481.0 | -392.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
