SDO HMI 2014-10-30 20:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.37 | 79.43 | 22.32 | 110.82 | -5.06 | 82.50 | -68.70 | 97.16 | 0.9360 | 438.0 | 200.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-30 20:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.73 | 0.00 | 2.15 | -4.46 | 85.26 | -65.94 | 96.86 | 0.9187 | -135.0 | -216.5 | |
| 11.00 | 65.82 | 14.67 | 87.68 | -4.94 | 83.55 | -67.65 | 97.17 | 0.9303 | 703.2 | 304.8 | |
| 4.68 | -2.00 | 6.30 | -2.00 | -4.33 | 83.28 | -67.93 | 96.48 | 0.9316 | 591.1 | 999999 | |
| 0.00 | 0.26 | 0.00 | 0.37 | -6.56 | 82.48 | -68.72 | 98.75 | 0.9382 | -174.0 | -200.0 | |
| 0.00 | 2.08 | 0.00 | 2.89 | -4.86 | 82.59 | -68.61 | 96.96 | 0.9362 | 40.0 | -10.4 | |
| 0.00 | 1.13 | 0.00 | 1.56 | -4.31 | 82.71 | -68.49 | 96.39 | 0.9351 | -299.0 | -280.9 | |
| 0.00 | 1.13 | 0.00 | 2.12 | -7.08 | 77.25 | -73.96 | 98.62 | 0.9658 | -147.0 | -179.9 | |
| 0.00 | 1.30 | 0.00 | 2.43 | -6.89 | 77.33 | -73.88 | 98.43 | 0.9653 | -177.0 | -226.2 | |
| 0.69 | 4.07 | 1.35 | 7.96 | -6.88 | 76.66 | -74.54 | 98.34 | 0.9683 | -60.1 | 20.8 | |
| 0.00 | 1.91 | 0.00 | 3.66 | -6.63 | 76.77 | -74.43 | 98.10 | 0.9677 | -224.0 | -225.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
