SDO HMI 2014-10-31 07:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.23 | 95.07 | 34.32 | 101.68 | -4.93 | 83.41 | -61.75 | 97.93 | 0.8875 | 372.3 | 149.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-31 07:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.38 | 79.12 | 3.43 | 82.95 | -4.84 | 84.98 | -60.18 | 98.07 | 0.8752 | -447.5 | 224.6 | |
| 0.00 | 1.56 | 0.00 | 1.58 | -4.48 | 84.97 | -60.19 | 97.66 | 0.8748 | -275.0 | -184.7 | |
| 0.00 | 0.87 | 0.00 | 0.89 | -3.63 | 84.65 | -60.51 | 96.65 | 0.8765 | 427.0 | 466.1 | |
| 5.72 | -1.00 | 5.97 | -1.00 | -5.10 | 84.20 | -60.96 | 98.25 | 0.8819 | 699.4 | 999999 | |
| 0.00 | 3.64 | 0.00 | 3.81 | -5.71 | 84.09 | -61.07 | 98.92 | 0.8835 | -167.0 | -104.9 | |
| 20.36 | -1.00 | 21.52 | -1.00 | -4.65 | 83.77 | -61.39 | 97.68 | 0.8848 | 614.6 | 999999 | |
| 1.47 | 2.60 | 1.60 | 2.82 | -4.77 | 82.92 | -62.24 | 97.69 | 0.8917 | 153.5 | 45.7 | |
| 0.00 | 1.56 | 0.00 | 1.69 | -4.26 | 82.94 | -62.22 | 97.12 | 0.8911 | -295.0 | -291.4 | |
| 0.00 | 2.08 | 0.00 | 2.89 | -6.89 | 76.87 | -68.29 | 99.13 | 0.9358 | -430.0 | -167.2 | |
| 1.30 | 2.95 | 1.80 | 4.08 | -6.56 | 76.88 | -68.27 | 98.77 | 0.9354 | -282.7 | -189.1 | |
| 0.00 | 0.69 | 0.00 | 0.97 | -7.06 | 76.65 | -68.51 | 99.27 | 0.9372 | 146.0 | 34.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
