SDO HMI 2014-11-01 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.14 | 21.19 | 3.62 | 13.01 | -16.86 | 98.82 | -29.32 | 127.29 | 0.5876 | -68.3 | 49.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-01 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.99 | 6.75 | 1.17 | 3.97 | -16.20 | 102.53 | -25.61 | 129.63 | 0.5410 | 1022.6 | 772.3 | |
| 4.15 | 6.40 | 2.45 | 3.78 | -16.28 | 102.21 | -25.93 | 129.40 | 0.5453 | 824.7 | 641.5 | |
| 0.00 | 0.52 | 0.00 | 0.31 | -15.65 | 99.24 | -28.91 | 125.57 | 0.5744 | 525.0 | 428.2 | |
| 0.00 | 0.95 | 0.00 | 0.59 | -16.36 | 97.33 | -30.81 | 124.93 | 0.6017 | -617.0 | -459.0 | |
| 0.00 | 1.90 | 0.00 | 1.23 | -17.16 | 94.19 | -33.95 | 123.57 | 0.6428 | -732.0 | -551.0 | |
| 0.00 | 0.26 | 0.00 | 0.17 | -18.97 | 93.78 | -34.36 | 125.68 | 0.6594 | -473.0 | -468.0 | |
| 0.00 | 0.95 | 0.00 | 0.62 | -17.47 | 93.55 | -34.59 | 123.53 | 0.6519 | -600.0 | -525.7 | |
| 0.00 | 1.30 | 0.00 | 0.88 | -19.59 | 91.57 | -36.57 | 124.90 | 0.6868 | -741.0 | -618.5 | |
| 0.00 | 0.95 | 0.00 | 0.65 | -19.79 | 91.36 | -36.79 | 125.01 | 0.6903 | -734.0 | -646.0 | |
| 0.00 | 1.21 | 0.00 | 0.81 | -17.02 | 91.66 | -36.48 | 121.61 | 0.6699 | -638.0 | -458.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
