SDO HMI 2014-11-01 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.48 | 27.70 | 9.61 | 26.37 | 6.23 | 69.23 | -58.91 | 85.33 | 0.8557 | -374.9 | -48.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-01 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.84 | 16.01 | 6.23 | 14.61 | 6.23 | 70.80 | -57.34 | 85.38 | 0.8418 | -691.2 | -436.0 | |
| 3.12 | -1.00 | 2.85 | -1.00 | 6.70 | 70.66 | -57.48 | 84.81 | 0.8430 | -529.0 | 999999 | |
| 0.00 | 1.47 | 0.00 | 1.36 | 6.34 | 70.16 | -57.98 | 85.23 | 0.8477 | -231.0 | -167.4 | |
| 0.00 | 0.95 | 0.00 | 0.91 | 6.77 | 68.92 | -59.22 | 84.70 | 0.8589 | -453.0 | -429.3 | |
| 0.00 | 1.04 | 0.00 | 1.00 | 6.34 | 68.77 | -59.37 | 85.20 | 0.8603 | -298.0 | -334.1 | |
| 0.00 | 0.87 | 0.00 | 0.84 | 6.07 | 68.64 | -59.50 | 85.52 | 0.8615 | -311.0 | -205.8 | |
| 0.52 | 1.47 | 0.53 | 1.51 | 6.21 | 66.72 | -61.43 | 85.29 | 0.8780 | 605.7 | 557.4 | |
| 0.00 | 1.82 | 0.00 | 1.89 | 5.52 | 66.27 | -61.87 | 86.06 | 0.8818 | 472.0 | 397.3 | |
| 0.00 | 4.07 | 0.00 | 4.25 | 5.91 | 66.20 | -61.94 | 85.62 | 0.8823 | 461.0 | 337.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
