SDO HMI 2014-11-01 15:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.53 | 47.59 | 7.46 | 24.46 | 12.85 | 114.68 | -12.91 | 55.38 | 0.2658 | -480.4 | -327.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-01 15:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.95 | 0.00 | 0.49 | 12.32 | 115.67 | -11.93 | 55.18 | 0.2470 | -660.0 | -447.6 | |
| 1.47 | 32.45 | 0.75 | 16.64 | 13.16 | 115.38 | -12.21 | 53.05 | 0.2590 | -1053.8 | -466.6 | |
| 6.66 | -2.00 | 3.41 | -2.00 | 12.82 | 115.36 | -12.23 | 54.14 | 0.2560 | -1061.5 | 999999 | |
| 0.00 | 1.30 | 0.00 | 0.67 | 12.70 | 115.09 | -12.50 | 55.13 | 0.2586 | -844.0 | -569.5 | |
| 1.99 | -2.00 | 1.02 | -2.00 | 13.09 | 114.85 | -12.74 | 54.38 | 0.2655 | -753.0 | 999999 | |
| 0.87 | -2.00 | 0.44 | -2.00 | 13.17 | 114.66 | -12.94 | 54.49 | 0.2690 | -759.9 | 999999 | |
| 0.95 | 2.86 | 0.49 | 1.46 | 12.03 | 114.68 | -12.91 | 58.14 | 0.2584 | -874.1 | -670.2 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 11.91 | 114.50 | -13.09 | 58.89 | 0.2600 | -841.0 | -723.2 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 12.11 | 113.58 | -14.01 | 59.87 | 0.2749 | 758.0 | 553.4 | |
| 1.64 | 3.46 | 0.85 | 1.79 | 13.21 | 113.37 | -14.23 | 56.80 | 0.2872 | -797.2 | -555.6 | |
| 0.00 | 2.16 | 0.00 | 1.12 | 12.76 | 113.20 | -14.39 | 58.45 | 0.2857 | 853.0 | 681.0 | |
| 0.95 | 2.51 | 0.50 | 1.31 | 12.76 | 111.43 | -16.16 | 61.18 | 0.3112 | 1039.5 | 828.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
