SDO HMI 2014-11-01 16:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.82 | 92.04 | 18.26 | 63.15 | -4.75 | 84.24 | -42.81 | 101.51 | 0.6932 | 360.0 | 241.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-01 16:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.78 | 0.00 | 0.51 | -7.61 | 88.12 | -38.92 | 107.00 | 0.6535 | 345.0 | 360.6 | |
| 0.00 | 1.12 | 0.00 | 0.75 | -6.03 | 86.40 | -40.64 | 104.02 | 0.6699 | 614.0 | 462.8 | |
| 0.00 | 1.12 | 0.00 | 0.75 | -5.35 | 86.14 | -40.90 | 102.95 | 0.6712 | -445.0 | -495.8 | |
| 0.00 | 1.12 | 0.00 | 0.75 | -4.41 | 86.22 | -40.82 | 101.59 | 0.6677 | 602.0 | 440.5 | |
| 0.00 | 0.87 | 0.00 | 0.58 | -6.49 | 85.72 | -41.32 | 104.45 | 0.6798 | -598.0 | -540.2 | |
| 0.00 | 1.38 | 0.00 | 0.93 | -5.98 | 85.49 | -41.55 | 103.65 | 0.6812 | -558.0 | -486.1 | |
| 0.00 | 0.87 | 0.00 | 0.58 | -4.38 | 85.54 | -41.50 | 101.36 | 0.6762 | 586.0 | 464.0 | |
| 0.00 | 1.30 | 0.00 | 0.88 | -5.78 | 85.35 | -41.69 | 103.31 | 0.6824 | -770.0 | -541.1 | |
| 0.00 | 0.78 | 0.00 | 0.53 | -5.27 | 85.23 | -41.81 | 102.55 | 0.6824 | -751.0 | -563.3 | |
| 4.85 | 10.90 | 3.30 | 7.41 | -5.68 | 84.91 | -42.13 | 103.03 | 0.6875 | 633.8 | 94.7 | |
| 0.00 | 0.95 | 0.00 | 0.65 | -5.30 | 84.71 | -42.34 | 102.42 | 0.6890 | 725.0 | 590.1 | |
| 13.15 | 48.80 | 8.93 | 33.18 | -4.28 | 84.71 | -42.34 | 100.96 | 0.6864 | 1030.0 | 511.0 | |
| 2.60 | 3.63 | 1.77 | 2.48 | -4.76 | 84.59 | -42.45 | 101.63 | 0.6891 | 710.9 | 582.6 | |
| 3.46 | -12.00 | 2.36 | -12.00 | -4.14 | 84.47 | -42.57 | 100.70 | 0.6890 | 823.6 | 999999 | |
| 0.00 | 1.56 | 0.00 | 1.07 | -5.02 | 84.36 | -42.68 | 101.92 | 0.6925 | 646.0 | 503.4 | |
| 1.12 | -12.00 | 0.77 | -12.00 | -3.91 | 84.16 | -42.88 | 100.30 | 0.6923 | 677.5 | 999999 | |
| 0.00 | 1.90 | 0.00 | 1.30 | -3.43 | 84.19 | -42.85 | 99.61 | 0.6909 | 634.0 | 466.5 | |
| 0.00 | 1.90 | 0.00 | 1.31 | -4.95 | 83.96 | -43.08 | 101.70 | 0.6973 | 531.0 | 498.2 | |
| 1.64 | 3.55 | 1.13 | 2.43 | -3.71 | 84.01 | -43.03 | 99.97 | 0.6938 | 691.4 | 523.4 | |
| 0.00 | 1.30 | 0.00 | 0.90 | -5.16 | 83.82 | -43.22 | 101.97 | 0.6996 | 471.0 | 337.1 | |
| 0.00 | 0.69 | 0.00 | 0.48 | -4.00 | 83.70 | -43.34 | 100.29 | 0.6982 | 322.0 | 260.8 | |
| 0.00 | 1.12 | 0.00 | 0.80 | -5.12 | 81.77 | -45.27 | 101.35 | 0.7240 | -762.0 | -678.5 | |
| 0.00 | 0.95 | 0.00 | 0.72 | -5.98 | 79.28 | -47.76 | 101.85 | 0.7547 | -662.0 | -568.6 | |
| 0.00 | 0.78 | 0.00 | 0.59 | -6.21 | 79.07 | -47.97 | 102.09 | 0.7575 | -680.0 | -611.4 | |
| 0.00 | 1.04 | 0.00 | 0.79 | -6.33 | 79.01 | -48.03 | 102.23 | 0.7584 | -638.0 | -569.4 | |
| 0.00 | 2.42 | 0.00 | 1.85 | -6.50 | 78.59 | -48.46 | 102.35 | 0.7636 | -649.0 | -561.9 | |
| 0.00 | 1.21 | 0.00 | 0.93 | -6.24 | 78.48 | -48.56 | 101.98 | 0.7641 | -626.0 | -507.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
