SDO HMI 2014-11-01 22:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.41 | 28.38 | 2.51 | 16.76 | -17.42 | 98.99 | -24.73 | 132.94 | 0.5423 | -110.3 | 43.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-01 22:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.86 | 0.00 | 1.61 | -18.13 | 106.23 | -17.49 | 142.97 | 0.4763 | 703.0 | 435.2 | |
| 0.00 | 1.73 | 0.00 | 0.98 | -16.42 | 102.95 | -20.77 | 135.78 | 0.4897 | 862.0 | 647.2 | |
| 1.12 | 2.60 | 0.64 | 1.47 | -16.33 | 102.76 | -20.96 | 135.39 | 0.4908 | 970.6 | 831.9 | |
| 3.29 | 9.17 | 1.87 | 5.21 | -16.25 | 102.48 | -21.25 | 134.87 | 0.4930 | 913.4 | 677.0 | |
| 0.00 | 1.21 | 0.00 | 0.71 | -16.69 | 99.18 | -24.54 | 131.51 | 0.5334 | 479.0 | 413.7 | |
| 0.00 | 0.87 | 0.00 | 0.52 | -19.27 | 97.92 | -25.81 | 133.73 | 0.5709 | -741.0 | -635.4 | |
| 0.00 | 1.64 | 0.00 | 1.02 | -18.70 | 93.93 | -29.80 | 129.04 | 0.6083 | -791.0 | -700.0 | |
| 0.00 | 2.16 | 0.00 | 1.35 | -18.63 | 93.40 | -30.33 | 128.46 | 0.6134 | -661.0 | -568.0 | |
| 0.00 | 0.78 | 0.00 | 0.48 | -17.21 | 93.52 | -30.20 | 126.63 | 0.6011 | -616.0 | -512.6 | |
| 0.00 | 1.12 | 0.00 | 0.70 | -17.53 | 93.43 | -30.30 | 127.00 | 0.6046 | -825.0 | -655.5 | |
| 0.00 | 0.87 | 0.00 | 0.54 | -17.90 | 93.10 | -30.62 | 127.22 | 0.6110 | -521.0 | -468.1 | |
| 0.00 | 2.16 | 0.00 | 1.39 | -19.67 | 91.47 | -32.25 | 128.22 | 0.6419 | -678.0 | -573.2 | |
| 0.00 | 0.69 | 0.00 | 0.45 | -19.36 | 91.28 | -32.44 | 127.65 | 0.6416 | -517.0 | -506.8 | |
| 0.00 | 0.52 | 0.00 | 0.33 | -17.00 | 91.59 | -32.13 | 124.73 | 0.6212 | -624.0 | -526.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
