SDO HMI 2014-11-02 07:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.83 | 78.35 | 16.39 | 60.49 | 5.83 | 68.50 | -50.29 | 85.94 | 0.7688 | -141.4 | 138.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-02 07:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.69 | 0.00 | 0.50 | 6.29 | 71.98 | -46.81 | 85.37 | 0.7294 | -547.0 | -422.4 | |
| 3.90 | 24.15 | 2.83 | 17.50 | 6.07 | 71.69 | -47.09 | 85.67 | 0.7328 | -844.4 | -588.3 | |
| 7.10 | -2.00 | 5.15 | -2.00 | 5.79 | 71.63 | -47.15 | 86.05 | 0.7335 | -849.9 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.63 | 6.46 | 71.25 | -47.54 | 85.14 | 0.7380 | -511.0 | -368.4 | |
| 5.63 | 7.88 | 4.19 | 5.86 | 5.81 | 70.33 | -48.45 | 86.01 | 0.7487 | -708.4 | -389.7 | |
| 0.00 | 1.30 | 0.00 | 0.98 | 6.28 | 69.55 | -49.24 | 85.38 | 0.7576 | -503.0 | -405.8 | |
| 0.00 | 1.30 | 0.00 | 0.99 | 6.46 | 69.06 | -49.72 | 85.14 | 0.7631 | -520.0 | -339.3 | |
| 0.00 | 2.94 | 0.00 | 2.30 | 5.18 | 68.04 | -50.74 | 86.79 | 0.7747 | -586.0 | -435.7 | |
| 0.00 | 1.04 | 0.00 | 0.82 | 5.66 | 67.60 | -51.18 | 86.16 | 0.7794 | 615.0 | 480.8 | |
| 0.00 | 4.07 | 0.00 | 3.24 | 6.71 | 67.03 | -51.76 | 84.82 | 0.7855 | 827.0 | 716.0 | |
| 0.00 | 1.30 | 0.00 | 1.04 | 6.60 | 66.80 | -51.99 | 84.95 | 0.7880 | 650.0 | 559.3 | |
| 0.00 | 1.82 | 0.00 | 1.46 | 6.08 | 66.63 | -52.16 | 85.60 | 0.7898 | 847.0 | 655.8 | |
| 0.00 | 1.21 | 0.00 | 0.98 | 5.93 | 66.55 | -52.24 | 85.80 | 0.7907 | 744.0 | 673.3 | |
| 1.56 | 4.76 | 1.26 | 3.85 | 6.19 | 66.32 | -52.47 | 85.47 | 0.7931 | 644.6 | 545.3 | |
| 0.00 | 3.03 | 0.00 | 2.45 | 5.65 | 66.29 | -52.49 | 86.15 | 0.7935 | 738.0 | 655.5 | |
| 0.87 | 3.38 | 0.70 | 2.74 | 5.97 | 66.15 | -52.63 | 85.74 | 0.7949 | 579.9 | 393.7 | |
| 2.77 | 12.64 | 2.26 | 10.27 | 5.33 | 66.03 | -52.75 | 86.54 | 0.7963 | 754.2 | 516.5 | |
| 0.00 | 5.28 | 0.00 | 4.31 | 5.69 | 65.94 | -52.85 | 86.09 | 0.7972 | 436.0 | 329.3 | |
| 0.00 | 0.69 | 0.00 | 0.57 | 5.05 | 65.87 | -52.92 | 86.89 | 0.7981 | 465.0 | 428.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
