SDO HMI 2014-11-03 07:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.45 | 74.14 | 12.36 | 39.27 | -4.31 | 86.72 | -18.88 | 114.06 | 0.3547 | 673.9 | 502.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-03 07:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.81 | 7.61 | 1.99 | 3.99 | -5.22 | 89.11 | -16.49 | 119.51 | 0.3262 | 1163.8 | 720.3 | |
| 0.00 | 0.78 | 0.00 | 0.41 | -5.48 | 88.26 | -17.34 | 118.95 | 0.3405 | -615.0 | -331.0 | |
| 0.00 | 0.87 | 0.00 | 0.46 | -5.24 | 88.14 | -17.46 | 118.17 | 0.3404 | 846.0 | 675.7 | |
| 0.00 | 2.60 | 0.00 | 1.36 | -4.07 | 88.08 | -17.52 | 114.96 | 0.3327 | 1049.0 | 808.0 | |
| 0.00 | 0.95 | 0.00 | 0.50 | -4.77 | 87.40 | -18.20 | 115.98 | 0.3477 | 867.0 | 700.8 | |
| 4.15 | 37.64 | 2.19 | 19.88 | -4.09 | 87.26 | -18.33 | 114.00 | 0.3450 | 1164.4 | 647.4 | |
| 10.56 | -6.00 | 5.57 | -6.00 | -3.97 | 87.11 | -18.49 | 113.51 | 0.3465 | 1181.7 | 999999 | |
| 0.43 | 2.25 | 0.23 | 1.19 | -4.96 | 87.05 | -18.55 | 116.03 | 0.3542 | 990.4 | 797.0 | |
| 0.00 | 2.08 | 0.00 | 1.09 | -3.16 | 87.10 | -18.50 | 111.31 | 0.3416 | -879.0 | -579.6 | |
| 4.50 | -6.00 | 2.38 | -6.00 | -4.01 | 86.83 | -18.77 | 113.28 | 0.3510 | 943.2 | 999999 | |
| 0.00 | 4.15 | 0.00 | 2.21 | -4.57 | 86.02 | -19.58 | 113.82 | 0.3667 | 711.0 | 709.2 | |
| 0.00 | 5.97 | 0.00 | 3.17 | -4.03 | 85.88 | -19.72 | 112.31 | 0.3654 | 901.0 | 699.9 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -4.63 | 85.80 | -19.80 | 113.74 | 0.3705 | 781.0 | 711.7 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -3.71 | 85.35 | -20.25 | 110.97 | 0.3716 | 769.0 | 545.1 | |
| 0.00 | 1.30 | 0.00 | 0.69 | -3.18 | 85.10 | -20.49 | 109.40 | 0.3722 | -905.0 | -662.7 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -4.46 | 84.37 | -21.23 | 111.86 | 0.3907 | 834.0 | 585.6 | |
| 0.00 | 0.78 | 0.00 | 0.42 | -5.12 | 84.31 | -21.29 | 113.38 | 0.3956 | 803.0 | 680.0 | |
| 0.00 | 1.12 | 0.00 | 0.61 | -5.76 | 82.90 | -22.70 | 113.46 | 0.4203 | 745.0 | 591.2 | |
| 0.00 | 1.12 | 0.00 | 0.62 | -5.82 | 81.73 | -23.87 | 112.55 | 0.4378 | -914.0 | -790.9 | |
| 0.00 | 1.56 | 0.00 | 0.87 | -5.71 | 79.52 | -26.08 | 110.55 | 0.4691 | -793.0 | -660.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
